Marantz SR6006/U1B - Page 159

159
Ref. No. Part No. Part Name Remarks Q'ty New
5 8U6331008000M PCB HDMI ASSY U1B COP12390L 1 *
5 8U6331008100M PCB HDMI ASSY N1B,N1SG COP12390M 1 *
5 8U6331010600M PCB HDMI ASSY K1B COP12390N 1 *
C1 - PCB FRONT HDMI -
C19 - PCB HDMI -
z
C12 943101012410S TRANS, POWER(EI96 X 65) U1B CLT5V059ZU 1
z
C12 943101012420S TRANS, POWER(EI96 X 75) N1B,N1SG CLT5V059ZE 1
z
C12 943101100210S TRANS, POWER(EI96 X 75) K1B CLT5V059ZH 1
C22 nsp TERMINAL,GROUND CMA1A006 1
C23 963183011000S MODULE, HD-RADIO U1B
CNVKSM-
H7101NNH-001
1
P1 963412013670M KNOB, VOLUME U1B,N1B,K1B CBN1A256 2
P1 963412013680M KNOB, VOLUME N1SG CBN1A256C73 2
P2 943424100270M ORNAMENT, VOLUME U1B,N1B,K1B CGR1A526B37 2
P2 943424100280M ORNAMENT, VOLUME N1SG CGR1A526RMD10 2
P3 943402101850M PANEL, FRONT U1B CGW1A512RHXH10 1 *
P3 943402101860M PANEL, FRONT N1B,K1B CGW1A512RHZH10 1 *
P3 943402101870M PANEL, FRONT N1SG CGW1A512RGYH64 1 *
P4 943419100320M JACK COVER ASS'Y U1B,N1B CGR1A518ZA 1
P4 943419100330M JACK COVER ASS'Y N1SG CGR1A518YA 1
P5 411510015017M KNOB, TACT POWER AV8003/U U1B,N1B,K1B CBT1A1072 1
P5 943411001970M KNOB, TACT POWER
N1SG CBT1A1072RMD10 1
P6 943411101410M KNOB, FUNCTION U1B,N1B,K1B CBT1A1158B37 1
P6 943411101420M KNOB, FUNCTION N1SG CBT1A1158RMD10 1
P7 00M10BW355010 INDICATOR,POWER CGL1A231 1
P8 943423100290M INDIACTOR, LED CGL1A294 2
P9 943424100250M ORNAMENT, RING U1B,N1B,K1B CGR1A525 1
P9 943424100260M ORNAMENT, RING N1SG CGR1A525C73 1
P10 416510046009M WINDOW CGU1A455 1
P11 416510047101M SHEET, VFD CGX1A449Y 1
P12 nsp SUPPORT, RING CMH1A320 1
P13 nsp SUPPORT, RC SENSOR CMH1A321 1
P14 481510019100M LENS IR U1B,N1B,K1B CGU1A460 1
P14 481510019131M LENS IR N1SG CGU1A460Y 1
P15 00M32CW107010 FOOT CUSHION CHG1A360 4
P16 90M243W057210 LEG FOR SILVER CKL2A042H46 4
P17 nsp RUBBER CHG1A113 4
P18 nsp HOLDER, PCB CHE170 5
P19 943419100250D CGX1A492Z SHEET TOP N1B,K1B CGX1A492Z 2
P19 943419100260D CGX1A492Y SHEET TOP N1SG CGX1A492Y 2
P20 45451000500AM STOPPER TOP BL PM6004 N1B,K1B CMH1A306Z 8
P20 45451000501AM STOPPER TOP SG PM6004 N1SG CMH1A306Y 8
P21 nsp SUPPORT, PCB CRE1A102 1
P22 nsp SUPPORT, PCB 31 CRE1A073 1
M1 421410006004M BADGE, MARANTZ CGB1A206 1
M2 nsp PLATE, EARTH CMC1A425 2
M3
nsp EARTH, RCA CMC1A426 1
s
