4. DIAGNOSTIC MODE (Video/Audio (signal) path conrmation mode)
This mode is used for conrming the Video and Audio (signal) paths. (Troubleshooting)
Conrming the operation of unit can be easily done after repair.
Backup data will not be lost.
4.1. Starting diagnostic mode
Press and hold both buttons ZONE SELECT and PURE DIRECT for over 3 second with the power turned on.
When this mode is operating, “DiagMode” is displayed in the upper level of the FL display.
4.2. Canceling diagnostic mode
Turn off the power by pressing the ON/Standby button.
4.3. Operation
When you perform remote operation in accordance with the instructions in "Details of how to operate remote controller" *a) in the table below using the remote control unit (RC014SR).
You will nd using another remote control unit with the macro functions very useful. To use the macro functions, program a macro function to output a remote control code in accordance with the steps in *b) in the table below.
4.4. Video system conrmation items
g.XX : Refer to the block diagram of the g.XXth.
Conrmation item Setting and display
Details of how to operate remote
controller *a)
Output sequence of remote control codes
※
It is useful to form a macro program. *b)
Contents of conrmation Remarks
1
Analog Video (signal) Path Video Convert (IP Scaler) : OFF , All Sources
All ZONE : ON
Display:
D i a g M o d e
V 0 1
D V D
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : CVBS / Output : CVBS
·Input : CVBS / Output : CVBS RECOUT
·Input : CVBS / Output : CVBS ZONE
·Input : Component / Output : Component
·Input : Component / Output : Component ZONE
4.Press [Z3]
5.Press [STANDBY]]
w
ZONE3 POWER OFF
6.Press [AMP]
7.Press [1/AUTO]
e
KEY1/AUTO (Main Zone)
(Initialization & Video Convert All OFF)
8.Press [Z2]
9.Press [POWER ON]
r
ZONE2 POWER ON
10.Press [Z3]
11.Press [POWER ON]
t
ZONE3 POWER ON
12.Press [AMP]
13.Press [DVD] twice
y
DVD (Main Zone)
2
Analog Video Convert (signal) Path Video Convert(IP Scaler) : ON , All Sources
Display:
D i a g M o d e
V 0 2
D V D
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : CVBS / Through : V.Decoder and V.Encoder / Output : CVBS
·Input : CVBS / Through : V.Decoder and V.Encoder / Output : Component
·Input : Input : Component / Through V.Decoder and V.Encoder / Output : CVBS
·Input : Component / Through V.Decoder and V.Encoder / Output : Component
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
6.Press [AMP]
7.Press [2/STEREO]
e
KEY2/STEREO (Main Zone)
(Initialization & Video Convert All ON
& IP Scaler "Analog & HDMI")
8.Press [DVD] twice
r
DVD (Main Zone)
3
HDMI (signal) Path Video Convert(IP Scaler) : OFF, All Sources
All ZONE:ON
Display:
D i a g M o d e
V 0 1
D V D
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : HDMI / Output : HDMI
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
6.Press [AMP]
7.Press [1/AUTO]
e
KEY1/AUTO (Main Zone)
(Initialization & Video Convert All OFF)
8.Press [Z2]
9.Press [POWER ON]
r
ZONE2 POWER ON
10.Press [Z3]
11.Press [POWER ON]
t
ZONE3 POWER ON
12.Press [AMP]
13.Press [DVD] twice
y
DVD (Main Zone)
4
Analog or HDMI to HDMI (signal) Path Video Convert(IP Scaler) : ON, All Sources
Display:
D i a g M o d e
V 0 2
D V D
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : CVBS / Through : IP Scaler / Output : HDMI
·Input : CVBS / Through : V.Decoder and V.Encoder / Output : Component
·Input : Component / Through : IP Scaler / Outpu : HDMI
·Input : HDMI / Through : IP Scaler / Outpu : HDMI
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
6.Press [AMP]
7.Press [2/STEREO]
e
KEY2/STEREO (Main Zone)
(Initialization & Video Convert All ON
& IP Scaler "Analog & HDMI")
8.Press [DVD] twice
r
DVD (Main Zone)
g.1
g.2
g.3
g.4
