Marantz SR6006/U1B - Parts List of Exploded View

158
PARTS LIST OF EXPLODED VIEW
z
Parts indicated by "nsp" on this table cannot be supplied.
z
P.W.B. ASS'Y indicated by "nsp" on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts list and order replacement parts.
z
Parts indicated by the "
★
" mark are not illustrated in the exploded view.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
Ref. No. Part No. Part Name Remarks Q'ty New
1 nsp PCB FRONT ASSY U1B,N1B,N1SG COP12383L 1 *
1 nsp PCB FRONT ASSY K1B COP12383P 1 *
C2 - PCB USB -
C3 - PCB FRONT -
C4 - PCB HP -
C5 - PCB HDMI FFC GUIDE -
C7 - PCB GUIDE L -
C8 - PCB GUIDE R -
C10 - PCB GUIDE TOP -
C9 nsp PCB 7CH_AMP ASSY U1B,N1B,N1SG COP12385G 1 *
C9 nsp PCB 7CH_AMP ASSY K1B COP12385I 1 *
2 nsp PCB CNT ASSY U1B COP12387L 1 *
2 nsp PCB CNT ASSY N1B,N1SG COP12387M 1 *
2 nsp PCB CNT ASSY K1B COP12387N 1 *
C11 - PCB FRONT CNT -
C16 - PCB SIDE CNT -
C21 - PCB RS232C -
3 nsp PCB MAIN ASSY U1B COP12386L 1 *
3 nsp PCB MAIN ASSY N1B,N1SG COP12386M 1 *
3 nsp PCB MAIN ASSY K1B COP12386N 1 *
C14 - PCB FUSE -
C15 - PCB SPK_PREOUT -
C20 - PCB RS232C CNT -
4 nsp PCB INPUT ASSY U1B COP12388L 1 *
4 nsp PCB INPUT ASSY N1B,N1SG COP12388M 1 *
4 nsp PCB INPUT ASSY K1B COP12388N 1 *
C13 - PCB POSISTOR -
C17 - PCB INPUT -
C18 nsp PCB VIDEO ASSY U1B,N1B,N1SG COP12389L 1 *
C18 nsp PCB VIDEO ASSY K1B COP12389P 1 *
C6 nsp PCB SMPS ASSY U1B COP12391B 1 *
C6 nsp PCB SMPS ASSY N1B,N1SG COP12391C 1 *
C6 nsp PCB SMPS ASSY K1B COP12391D 1 *
