Marantz SR6006/U1B - Parts List of P.C.b. Unit; Pcb.front.assy

194
PARTS LIST OF P.C.B. UNIT
z
Parts indicated by "nsp" on this table cannot be supplied.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
PCB FRONT ASSY
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC601,602 00D2631289900 IC AZ4580MTR-E1 CVIAZ4580MTR-E1
IC603 00MHC9150609Y IC NJM2887DL3 CVINJM2887DL3
Q6001 943216500020S TR RT1N141C CVTRT1N141C
Q6003 943219006820S TR KTC1027Y CVTKTC1027YT
Q6005,6006 943216500020S TR RT1N141C CVTRT1N141C
Q6011,6012 943216500020S TR RT1N141C CVTRT1N141C
Q6013 943215500020S TR RT1P141C CVTRT1P141C
Q6016 943216500020S TR RT1N141C CVTRT1N141C
Q7125 963219003340S T.R, BIAS KTC3964 CVTKTC3964
Q7131 00D9630235301 T.R Power, 2SD2560 HVT2SD2560
Q7132 00D9630235204 T.R Power, 2SB1647 HVT2SB1647
Q7225 963219003340S T.R, BIAS KTC3964 CVTKTC3964
Q7231 00D9630235301 T.R Power, 2SD2560 HVT2SD2560
Q7232 00D9630235204 T.R Power, 2SB1647 HVT2SB1647
Q7325 963219003340S T.R, BIAS KTC3964 CVTKTC3964
Q7331 00D9630235301 T.R Power, 2SD2560 HVT2SD2560
Q7332 00D9630235204 T.R Power, 2SB1647 HVT2SB1647
Q7425 963219003340S T.R, BIAS KTC3964 CVTKTC3964
Q7431 00D9630235301 T.R Power, 2SD2560 HVT2SD2560
Q7432 00D9630235204 T.R Power, 2SB1647 HVT2SB1647
Q7525 963219003340S T.R, BIAS KTC3964 CVTKTC3964
Q7531 00D9630235301 T.R Power, 2SD2560 HVT2SD2560
Q7532 00D9630235204 T.R Power, 2SB1647 HVT2SB1647
Q7625 963219003340S T.R, BIAS KTC3964 CVTKTC3964
Q7631 00D9630235301 T.R Power, 2SD2560 HVT2SD2560
Q7632 00D9630235204 T.R Power, 2SB1647 HVT2SB1647
Q7725 963219003340S T.R, BIAS KTC3964 CVTKTC3964
Q7731 00D9630235301 T.R Power, 2SD2560 HVT2SD2560
Q7732 00D9630235204 T.R Power, 2SB1647 HVT2SB1647
D6003 00D2760794900 DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP
D6005-6007 00D9630328409 DIODE, RECTIFIER, AXIAL CVD1N4007ST
D6015 00D9430087209 ZENER DIODE ZJ24B 1/2W CVDZJ24BT
D6016 943202007690S DIODE, ZENER 18V CVDZJ18BT
D6018 00D9630328409 DIODE, RECTIFIER, AXIAL CVD1N4007ST
D6019 nsp COPPER WIRE C3A206
D6022-6024 00D2760694903 DIODE, ZENER (CHIP,5.1V) HVDUDZS5.1BSR
D6028,6029 963263012110S LED, SUPER RED CVDBLBUF4V5K1AV
D6034-6036 963209003510S DIODE, RELIABLE ESD PROTECTION CVDCDS3C05HDMI1
D6037 963263012100S LED, RED/YELLOW GREEN CVDBLBVT201GTBS20V
CAPACITORS GROUP
C6001 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C6003 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6006-6008 nsp CHIP CAP 100PF 50V J CCUS1H101JA
C6009 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6010 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C6011-6013 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6015 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6017 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6029 943134010530S ELECT CAP 1UF 50V C CCEA1HH1R0T
C6031 nsp COPPER WIRE C3A206
C6032 943134501530S CAP, ELECT(63V/470uF) CCEA1JH471
C6033,6034 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6039,6040 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6041 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C6042 nsp CHIP CAP 100PF 50V J CCUS1H101JA
C6043 943134501540S CAP, ELECT(50V/1uF)-S CCEA1HKS1R0T
C6045 nsp CAP, CHIP(1608, 50V/0.047uF) CCUS1H473KC
