Marantz SR6006/U1B - Pcb.hdmi.assy

214
PCB HDMI ASSY
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 nsp I.C, HDMI BUFFER CVIAD8195ACPZ
IC111 236810057606S I.C, HDMI MUX CVIADV3002BSTZ
IC112 234810018506S I.C, ANALOG MUX/DeMUX CVITC74VHC4052AFT
IC121 nsp I.C, HDMI RX/Decoder(BGA-425P) CVIADV7844KBCZ
IC122 963239002150S I.C, OCTAL BUFFER/DRIVER CVISN74LVC244APWR
IC151 nsp I.C, VSP(ADV8002-1) CVIADV8002KBCZ
IC152,153 nsp
I.C, DDR2
SDRAM(1G,800MHZ,FBGA)
CVIK4T1G164QF-BCF7
IC155 943248100930S
I.C, OSD SERIAL FLASH(SR6006/
MX25L6406EM21-12G)
U1B,N1B,
N1SG
CVIANAM1576AV
IC155 943248100940S
I.C, OSD SERIAL FLASH(SR6006/
MX25L6406EM21-12G)
K1B CVIANAM1577AV
IC156 943239010400S I.C, REGULATOR(1.8V/TO-252) CVINJM2845DL118
IC201 943243100720S
I.C, MAIN MCU(SR6006/
R5F5630ECDFB)
U1B,N1B,
N1SG
CVIANAM1582AV
IC201 943243100730S
I.C, MAIN MCU(SR6006/
R5F5630ECDFB)
K1B CVIANAM1583AV
IC202 246810026500S I.C EEPROM(256K, 32-kword x 8 bit) CVIR1EX24256ASAS0A
IC231 943243100740S
I.C, SUB MCU(SR6006/
R5F3650KNFB)
CVIANAM1598AV
IC241 00D2623448908 I.C, 3STATE QUAD BUFFER CVITC74VHC125FT
IC242 00D2623437906 I.C, OCTAL BUS BUFFER CVITC74VHCT244AFT
IC243 00D2623444902 IC TC74VHC08FT N1B,N1SG CVITC74VHC08FT
IC301-305 nsp IC EX3AV CVIEX3AV
IC306,307 943239010400S REGULATOR IC NJM2845DL133 CVINJM2845DL133
IC308 234810015507S I.C, VOLTAGE DETECTOR(4.8V) CVIBU4248F-TR
IC309 nsp IC EX3AV CVIEX3AV
IC320 943652500030S POLY SWITCH (1.6A, 8V) CBA5H1600PSUYT
IC321 103810002508S
Pulse-Trans(HIGH SPEED LAN
MAGNETICS)
CVIS558-5999U7F
IC322 nsp I.C, ETHERNET PHY CVILAN8700CAEZGTR
IC323 00D2623711004 I.C, VIDEO ENCODER CVISAA7121H/V2.518
IC324 nsp
I.C, IPOD AUTHENTICATION CHIP
FROM MARANTZ
CVI236710076509S-DM
IC390 nsp
I.C, IPOD AUTHENTICATION CHIP
FROM MARANTZ
CVIDM860
IC391 nsp
I.C, NETWORK NAND
FLASH(SR6006U/H27U1G8F2BTR-BC)
U1B CVIANAM1592AV
IC391 nsp
I.C, NETWORK NAND
FLASH(SR6006U/H27U1G8F2BTR-BC)
N1B,N1SG CVIANAM1593AV
IC391 nsp
I.C, NETWORK NAND
FLASH(SR6006U/H27U1G8F2BTR-BC)
K1B CVIANAM1595AV
IC392 246810063608S I.C, 256M SDRAM CVIW9825G6JH-6
IC401 00D2623077900 I.C, HEX INVERTER HVITC74VHCU04FT
IC403-405 236810062608S I.C, DIR CVILC89058W-E
IC406 943236101000S I.C, PLD(EPM240T100C5N) CVIANAM1602AV
IC407 236810083506S I.C, CLOCK JITTER CVICS210010-CZZR
IC408 nsp I.C, DSP(LQFP-176P/400M) CVIADSP21487KSWZ-4B
IC409 943246012690S I.C, 64M SDRAM CVIW9864G6JH-6
NOTE :
When update
Firmware,
please conrm
a last version in
SDI.
Use the service
board after
updating it.
