Marantz SR6006/U1B - Pcb.smps.assy

212
PCB SMPS ASSY
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
z
IC901 231010091708S I.C, OFF-LINE POWER SWITCH CVITOP258MG
z
IC902 963239010480S I.C, PHOTOCOUPLER CVIPC123Y22FZ0F
IC903 212050010508S I.C, SHUNT REGULATOR(TO-92) CVIKIA2431AP
Q9001-9003 00MHT30001000 TR KTC3199Y HVTKTC3199YT
D9001-9006 00D9630328409 DIODE, RECTIFIER, AXIAL CVD1N4007ST
D9008,9009 00D9630328409 DIODE, RECTIFIER, AXIAL CVD1N4007ST
D9010 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D9012 943209500030S
DIODE, LOW FORWARD SCHOTTKY
RECTIFIER
CVDSRL3060P
D9013 963209010430S DIODE, RECTIFIER CVDAP01CT
CAPACITORS GROUP
z
C9001-9003 963132011940S CAP, CERAMIC(X1/Y2,0.01uF,AC250V) CCKDKY103MFM
C9004 943134501590S CAP, ELECT(200V/100uF)105, 16X20 U1B CCET200NHA101ES
C9004 963134010200S CAP, ELECT(200V/100uF)105, 16X20 N1B,N1SG,K1B CCET400NHA101ES
C9006-9008 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C9009 00D9430175108 CAP, ELECT(50V/10uF) CCEA1HNXA100TS
C9010 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C9012 963132010120S CAP, CERAMIC(DC1KV/1000pF) CCKDDEH102KCM
C9016 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C9017 00MOA47602520 CAP, ELECT(25V/47uF) CCEA1ENXA470TS
C9018 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C9019 nsp CAP, CHIP(1608,6.3V/4.7uF) CCUS0J475KC
C9020-9022 963134010220S CAP, ELECT(6.3V/5600uF) CCEA0JNXA562ES
C9024 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
z
C9028 963132011930S CAP, CERAMIC(X1/Y1,2200P,AC250V) CCKDKX222MEM
C9029 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
RESISTORS GROUP
R9021 nsp RES, CHIP(1608/1%/22Kohm) CRJ10DF2202T
R9024 nsp RES, CHIP(1608/1%/6.8Kohm) CRJ10DF6801T
z
R9031-9034 943121500030S RES, CHIP(2012/5%/2.2Mohm) CRJ18AJ225T
OTHERS PARTS GROUP
BK901 nsp PCB BRACKET CMD1A188
BK903 nsp BRACKET, PCB CMD1A629
BN903 nsp
WIRE ASS'Y LOCKING
(5P,2.5MM,400MM,UL1569#22,105)
CWB7D0054003D001
CN902 nsp WAFER 2PIN CJP02GA89ZY
z
CX901 943139500020S
CAP, POLYPROPYLENE FILM
(0.1uF/275VAC)
CCQF2E104KZE-T
z
CY901,902 963134011730S CAP, CERAMIC(X1/Y1,470P,AC250V) CCKDKX471KBM
