Marantz SR6006/U1B - Page 166

166
Pin Pin Name Synbol Tolerant I/O Pu/Pd LvCnv STBY stop Function
102
PE6/TIOCA11/
IRQ6-C/AN4
PRE Z3 MUTE O O/L O/L PRE OUT MUTE control
103 PK5/TXD4-B NC O O/L O/L NC
104 P70/SCK4-B NC O O/L O/L NC
105 PK4/RXD4-B NC O O/L O/L NC
106
PE5/TIOCB10/
IRQ5-C/AN3
NC O O/L O/L NC
107 PE4/TIOCA10/AN2 VOL CLK O O/L O/L FUNCTION/VOLUME control(R2A15220)
108 PE3/TIOCB9/AN1 VOL DATA O O/L O/L FUNCTION/VOLUME control(R2A15220)
109
PE2/TIOCA9/
RXD12/IRQ7-DS/
AN0
NC O O/L O/L NC
110
PE1/TIOCD9/
TXD12/ANEX1
NC O O/L O/L NC
111
PE0/TIOCC9/
ANEX0/SCK12
NC O O/L O/L NC
112 P64 ZVOL STB O O/L O/L ZONE VOL (NJW1194) control
113 P63 ZVOL DATA O O/L O/L ZONE VOL (NJW1194) control
114 P62 ZVOL CLK O O/L O/L ZONE VOL (NJW1194) control
115 P61 THERMAL C I I I PROTECTION detection pin(THERMAL C)
116 PK3/RXD9-B NC O O/L O/L NC
117 P60/SCK9-B NC O O/L O/L NC
118 PK2/TXD9-B NC O O/L O/L NC
119 PD7/IRQ7-D/AN7 FL RST O O/L O/L FL display control pin
120 PD6/IRQ6-D/AN6 FL CE O O/L O/L Pin for FL display control
121 PD5/IRQ5-D/AN013 FL CLK O O/L O/L Pin for FL display control
122 PD4/IRQ4-D/AN012 FL DATA O O/L O/L Pin for FL display control
123
PD3/TIOCB8/
IRQ3-C/AN011
ASO DET I I I PROTECTION detection pin(ASO)
124
PD2/TIOCA8/
IRQ2-C/AN010
DC DET I I I PROTECTION detection pin(DC DET)
125
PD1/TIOCB7/
IRQ1-C/AN009
ETHER POWER O O/L O/L ETHER POWER control pin
126
PD0/TIOCA7/
IRQ0-C/AN008
D5V POWER O O/L O/L Digital 5V power supply control pin (D5V→3.3V,1.8V,1.2V)
127 P93/AN017 MAIN POWER O O/L O/L MAIN POWER control pin
128 P92/RXD7/AN016 CPU POWER O O/L O/L
Cntrol pin for MAIN CPU POWER (POWER ON:H)
STANDBY(CEC ON):H)
129 P91/AN015/SCK7 (MUTE POWER) O L L Reserve(power supply control pin for PRE MUTE TR)
130 VSS VSS - - - GND
131 P90/TXD7/AN014 REMOTE POWER(232C) O O/L O/L Pin for 232C POWER control(ON:H)
132 VCC VCC - - - Power supply pin
133
P47/IRQ15-DS/
AN007
MIC DET I I O/L Pin for MIC detection pin(At detection:H)
134
P46/IRQ14-DS/
AN006
H/P DET I I O/L Pin for Headphone detection pin(At detection:H)
135
P45/IRQ13-DS/
AN005
KEY3 I M3VPu I I KEY input 3(STANDBY:Interrupt setting)
136
P44/IRQ12-DS/
AN004
KEY2 I M3VPu I I KEY input 2(STANDBY:Interrupt setting)
137
P43/IRQ11-DS/
AN003
KEY1 I M3VPu I I KEY input 1(STANDBY:Interrupt setting)
138
P42/IRQ10-DS/
AN002
(MODEL) I I I Not use (MODEL Switch input)
139
P41/IRQ9-DS/
AN001
MODE I I I Region switch input
140 VREFL0 VREFL0 - - - GND
141
P40/IRQ8-DS/
AN000
THERMAL D I I I PROTECTION detection pin(THERMAL D)
142 VREFH0 VREFH0 - - - Standard power supply input
143 AVCC0 AVCC0 - - - Analog power supply
144 P07/IRQ15-B POWER KEY ○ I M3VPu I I POWER KEY(WAIT MODE release,Interrupt port)
