Check TV
(11) Is the TV HDCP-compatible?
(16) Is the set's input set to HDMI?
Is the output setting of set corresponding to the connection of TV?
(15) Is any PIN of the HDMI connector bent or is dust adhering to the
connector?
(13) Is the TV's input set to HDMI?
(14) Are the picture and sound output when a different TV is used?
Check set (AV RECEIVER)
(12) Is the TV compatible with resolutions of 1080P?
Use an HDCP-compatible TV. PC TVs
cannot be used.
Check the set's input setting, referring to the
set's operating instructions.
Malfunction of the HDMI connector.
(If dust is adhering, remove the dust and
perform the troubleshooting again from (1).)
Check the TV's input setting, referring to the
TV's operating instructions.
The TV is defective.
If the TV is not compatible with resolutions
of 1080P, no picture will be output, even
if the BD/DVD player's resolution is set to
1080P.
NO
NO
YES
NO
NO
NO
YES
NO
YES
The set does not recognize
the TV.
(MONITOR OUT: Set
MONITOR1)
(17) Is the "H"(3V-5V) signal
outputted of TP[HPD] in the
vicinity of JK151?
With the TV
connected,check the
voltage of the IC on the
side on which the TV is
connected.
Is communication
waveform conrmed in
TP[DDC_CLK/DDC_
DATA] in the HDMI
connector (JK151)?
Is D1601/D1602/D1603/
D1604/D1605/D1606/
D1607/D1608 terminated
by the TMDS signal of
3.3V and is the signal
output?
The set does not recognize
the TV.
(MONITOR OUT: Set
MONITOR2)
(32) Is the "H"(3V-5V) signal
outputted of TP[HPD] in the
vicinity of JK152?
With the TV
connected,check the
voltage of the IC on the
side on which the TV is
connected.
Is communication
waveform conrmed in
TP[DDC_CLK/DDC_
DATA] in the HDMI
connector (JK152)?
Is D1613/D1614/D1615/
D1616/D1617/D1618/
D1619/D1620 terminated
by the TMDS signal of
3.3V and is the signal
output?
The pattern and circuit from the HDMI
connector (JK151) to the IC151 is defective,
or HDMI output circuitry is defective (IC151
and surrounding circuitry).
The pattern and circuit from the HDMI
connector (JK151/152) to the IC151 is
defective, or HDMI output circuitry is
defective (IC151 and surrounding circuitry).
