Marantz SR8001 Service Manual

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
AMP C519 ns
p
90M-OA000120R ELECT CAP. 100UF 50V HCEA1HAHS101T
AMP C520 ns
p
90M-OA000120R ELECT CAP. 100UF 50V HCEA1HAHS101T
AMP C521 ns
p
00MOA10702520 ELECT CAP. 100UF 25V CCEA1EH101T
AMP C522 ns
p
00MOA10702520 ELECT CAP. 100UF 25V CCEA1EH101T
AMP C601 ns
p
90M-OA000140R ELECT CAP. 10UF 50V HCEA1HROA100T
AMP C602 ns
p
90M-OA000140R ELECT CAP. 10UF 50V HCEA1HROA100T
AMP C603 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
AMP C604 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
AMP C605 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100DC
AMP C606 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100DC
AMP C607 90M-OF100350R 90M-OF100350R FILM CAP. 2200PF 50V J HCQI1H222JZT
AMP C608 90M-OF100350R 90M-OF100350R FILM CAP. 2200PF 50V J HCQI1H222JZT
AMP C609 ns
p
90M-OA000130R ELECT CAP. 22UF 50V HCEA1HAHS220T
AMP C610 ns
p
90M-OA000130R ELECT CAP. 22UF 50V HCEA1HAHS220T
AMP C611 ns
p
00MOA10710020 ELECT CAP. 100UF 100V CCEA2AH101E
AMP C612 ns
p
00MOA10710020 ELECT CAP. 100UF 100V CCEA2AH101E
AMP C613 ns
p
00MOA10710020 ELECT CAP. 100UF 100V CCEA2AH101E
AMP C614 ns
p
00MOA10710020 ELECT CAP. 100UF 100V CCEA2AH101E
AMP C619 ns
p
90M-OA000120R ELECT CAP. 100UF 50V HCEA1HAHS101T
AMP C620 ns
p
90M-OA000120R ELECT CAP. 100UF 50V HCEA1HAHS101T
AMP C621 ns
p
00MOA10702520 ELECT CAP. 100UF 25V CCEA1EH101T
AMP C622 ns
p
00MOA10702520 ELECT CAP. 100UF 25V CCEA1EH101T
AMP C701 ns
p
90M-OA000140R ELECT CAP. 10UF 50V HCEA1HROA100T
AMP C703 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
AMP C705 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100DC
AMP C707 90M-OF100350R 90M-OF100350R FILM CAP. 2200PF 50V J HCQI1H222JZT
AMP C709 ns
p
90M-OA000130R ELECT CAP. 22UF 50V HCEA1HAHS220T
AMP C711 ns
p
00MOA10710020 ELECT CAP. 100UF 100V CCEA2AH101E
AMP C713 ns
p
00MOA10710020 ELECT CAP. 100UF 100V CCEA2AH101E
AMP C719 ns
p
90M-OA000120R ELECT CAP. 100UF 50V HCEA1HAHS101T
AMP C721 ns
p
00MOA10702520 ELECT CAP. 100UF 25V CCEA1EH101T
AMP C722 ns
p
00MOA10702520 ELECT CAP. 100UF 25V CCEA1EH101T
AMP C810 90M-OF100490R 90M-OF100490R FILM CAP. 0.1UF 250V KCME2E104JP04T
AMP C811 90M-OF100490R 90M-OF100490R FILM CAP. 0.1UF 250V KCME2E104JP04T
AMP C812 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
AMP C813 ns
p
00MOA47605020 ELECT CAP. 47UF 50V CCEA1HH470T
AMP C814 ns
p
00MOA47505020 ELECT CAP. 4.7UF 50V CCEA1HH4R7T
AMP C815 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
AMP C816 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
AMP CN23 ns
p
ns
p
CONN. STRAIGHT 8PIN CJP08GA19ZY
AMP CN24 ns
p
ns
p
CONN. 6P STRAIGHT CJP06GA19ZY
AMP CN41 ns
p
ns
p
CONN. STRAIGHT, 2PIN CJP02GA01ZY
AMP CN42 ns
p
ns
p
CONN. STRAIGHT, 2PIN CJP02GA01ZY
AMP CN51 ns
p
ns
p
CONN. STRAIGHT, 2PIN CJP02GA01ZY
AMP CN52 ns
p
ns
p
CONN. STRAIGHT, 2PIN CJP02GA01ZY
AMP CN61 ns
p
ns
p
CONN. STRAIGHT, 2PIN CJP02GA01ZY
AMP CN62 ns
p
ns
p
CONN. STRAIGHT, 2PIN CJP02GA01ZY
AMP CN71 ns
p
ns
p
CONN. STRAIGHT, 2PIN CJP02GA01ZY
AMP CN73 ns
p
ns
p
CONN. A3963WV2-6P CJP06GA148ZW
AMP CN81 ns
p
ns
p
CONN. 2PIN CJP02GA19ZY CJP02GA19ZY
AMP CN82 ns
p
ns
p
CONN. 2PIN CJP02GA19ZY CJP02GA19ZY
AMP CN83 ns
p
ns
p
CONN. STRAIGHT, 2PIN CJP02GA01ZY
AMP CN83 ns
p
ns
p
CORD WIRE ASSY CWZSR7001CN83
AMP D401 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D402 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D403 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D404 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D405 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D406 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D407 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D408 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D409 90M-HD302380R 90M-HD302380R ZENER DIODE ZJ3.6BT CVDZJ3.6BT
AMP D410 90M-HD302380R 90M-HD302380R ZENER DIODE ZJ3.6BT CVDZJ3.6BT
AMP D411 90M-HD302380R 90M-HD302380R ZENER DIODE ZJ3.6BT CVDZJ3.6BT
AMP D412 90M-HD302380R 90M-HD302380R ZENER DIODE ZJ3.6BT CVDZJ3.6BT
AMP D413 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D414 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
177
