Marantz SR8001 Service Manual

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
AMP D415 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D416 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D501 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D502 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D503 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D504 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D505 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D506 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D507 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D508 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D509 90M-HD302380R 90M-HD302380R ZENER DIODE ZJ3.6BT CVDZJ3.6BT
AMP D510 90M-HD302380R 90M-HD302380R ZENER DIODE ZJ3.6BT CVDZJ3.6BT
AMP D511 90M-HD302380R 90M-HD302380R ZENER DIODE ZJ3.6BT CVDZJ3.6BT
AMP D512 90M-HD302380R 90M-HD302380R ZENER DIODE ZJ3.6BT CVDZJ3.6BT
AMP D513 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D514 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D515 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D516 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D601 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D602 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D603 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D604 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D605 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D606 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D607 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D608 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D609 90M-HD302380R 90M-HD302380R ZENER DIODE ZJ3.6BT CVDZJ3.6BT
AMP D610 90M-HD302380R 90M-HD302380R ZENER DIODE ZJ3.6BT CVDZJ3.6BT
AMP D611 90M-HD302380R 90M-HD302380R ZENER DIODE ZJ3.6BT CVDZJ3.6BT
AMP D612 90M-HD302380R 90M-HD302380R ZENER DIODE ZJ3.6BT CVDZJ3.6BT
AMP D613 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D614 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D615 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D616 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D701 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D703 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D705 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D707 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D709 90M-HD302380R 90M-HD302380R ZENER DIODE ZJ3.6BT CVDZJ3.6BT
AMP D711 90M-HD302380R 90M-HD302380R ZENER DIODE ZJ3.6BT CVDZJ3.6BT
AMP D713 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D715 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
AMP D801 90M-HE200250R 90M-HE200250R DIODE ! GBJ1504 HVDGBJ1504
AMP D802 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
AMP D803 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
AMP D804 90M-HD302390R 90M-HD302390R ZENER DIODE ZJ3.3BT CVDZJ3.3BT
AMP D805 90M-HD302390R 90M-HD302390R ZENER DIODE ZJ3.3BT CVDZJ3.3BT
AMP D806 90M-HD302390R 90M-HD302390R ZENER DIODE ZJ3.3BT CVDZJ3.3BT
AMP IC41 00MHC10053090 00MHC10053090 IC NJM2068DD HVINJM2068DD
AMP IC51 00MHC10053090 00MHC10053090 IC NJM2068DD HVINJM2068DD
AMP IC61 00MHC10053090 00MHC10053090 IC NJM2068DD HVINJM2068DD
AMP IC71 00MHC10053090 00MHC10053090 IC NJM2068DD HVINJM2068DD
AMP J101 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
AMP J102 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
AMP J103 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
AMP J104 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
AMP J105 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
AMP J106 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
AMP J107 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
AMP J108 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
AMP J109 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
AMP J110 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
AMP J111 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
AMP J112 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
AMP J113 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
AMP J114 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
AMP J115 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
178
