Marantz SR8001 - Page 191

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
INPUT R392 ns
p
00MNN05473610 CHIP RES. 47K OHM 1/10W J CRJ10DJ473T
INPUT R393 ns
p
00MNN05473610 CHIP RES. 47K OHM 1/10W J CRJ10DJ473T
INPUT R394 ns
p
00MNN05221610 CHIP RES. 220 OHM 1/10W J CRJ10DJ221T
INPUT R395 ns
p
00MNN05221610 CHIP RES. 220 OHM 1/10W J CRJ10DJ221T
INPUT R396 ns
p
00MNN05105610 CHIP RES. 1M OHM 1/10W J CRJ10DJ105T
INPUT R397 ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T
INPUT R398 ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T
INPUT R399 ns
p
00MNN05221610 CHIP RES. 220 OHM 1/10W J CRJ10DJ221T
INPUT R400 ns
p
00MNN05221610 CHIP RES. 220 OHM 1/10W J CRJ10DJ221T
INPUT R401 ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T
INPUT R402 ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T
INPUT R403 ns
p
00MNN05330610 CHIP RES. 33 OHM 1/10W J CRJ10DJ330T
INPUT R404 ns
p
00MNN05330610 CHIP RES. 33 OHM 1/10W J CRJ10DJ330T
INPUT R405 ns
p
00MNN05473610 CHIP RES. 47K OHM 1/10W J CRJ10DJ473T
INPUT R406 ns
p
00MNN05102610 CHIP RES. 1K OHM 1/10W J CRJ10DJ102T
INPUT R407 ns
p
00MNN05473610 CHIP RES. 47K OHM 1/10W J CRJ10DJ473T
INPUT R408 ns
p
00MNN05102610 CHIP RES. 1K OHM 1/10W J CRJ10DJ102T
INPUT R409 ns
p
00MNN05822610 CHIP RES. 8.2K OHM 1/10W J CRJ10DJ822T
INPUT R410 ns
p
00MNN05822610 CHIP RES. 8.2K OHM 1/10W J CRJ10DJ822T
INPUT R411 ns
p
00MNN05473610 CHIP RES. 47K OHM 1/10W J CRJ10DJ473T
INPUT R412 ns
p
00MNN05473610 CHIP RES. 47K OHM 1/10W J CRJ10DJ473T
INPUT R413 ns
p
00MNN05221610 CHIP RES. 220 OHM 1/10W J CRJ10DJ221T
INPUT R414 ns
p
00MNN05221610 CHIP RES. 220 OHM 1/10W J CRJ10DJ221T
INPUT R415 ns
p
00MNN05105610 CHIP RES. 1M OHM 1/10W J CRJ10DJ105T
INPUT R416 ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T
INPUT R417 ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T
INPUT R418 ns
p
00MNN05221610 CHIP RES. 220 OHM 1/10W J CRJ10DJ221T
INPUT R419 ns
p
00MNN05221610 CHIP RES. 220 OHM 1/10W J CRJ10DJ221T
INPUT R420 ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T
INPUT R421 ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T
INPUT R422 ns
p
00MNN05330610 CHIP RES. 33 OHM 1/10W J CRJ10DJ330T
INPUT R423 ns
p
00MNN05330610 CHIP RES. 33 OHM 1/10W J CRJ10DJ330T
INPUT R424 ns
p
00MNN05100610 CHIP RES. 10 OHM 1/10W J CRJ10DJ100T
INPUT R425 ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T
INPUT R426 ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T
INPUT R427 ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T
INPUT R428 ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T
INPUT R429 ns
p
00MNN05102610 CHIP RES. 1K OHM 1/10W J CRJ10DJ102T
INPUT R430 ns
p
00MNN05224610 CHIP RES. 220K OHM 1/10W J CRJ10DJ224T
INPUT R431 ns
p
00MNN05224610 CHIP RES. 220K OHM 1/10W J CRJ10DJ224T
INPUT R432 ns
p
00MNN05224610 CHIP RES. 220K OHM 1/10W J CRJ10DJ224T
INPUT R433 ns
p
00MNN05224610 CHIP RES. 220K OHM 1/10W J CRJ10DJ224T
INPUT R434 ns
p
00MNN05224610 CHIP RES. 220K OHM 1/10W J CRJ10DJ224T
INPUT R435 ns
p
00MNN05224610 CHIP RES. 220K OHM 1/10W J CRJ10DJ224T
INPUT R436 ns
p
00MNN05224610 CHIP RES. 220K OHM 1/10W J CRJ10DJ224T
INPUT R437 ns
p
00MNN05224610 CHIP RES. 220K OHM 1/10W J CRJ10DJ224T
INPUT R438 ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T
INPUT R439 ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T
INPUT R440 ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T
INPUT R441 ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T
INPUT RY90 90M-LY000430R 90M-LY000430R RELAY RELAY
(
BA1-5H
)
CSL1C003ZU
INPUT RY91 90M-LY000430R 90M-LY000430R RELAY RELAY
(
BA1-5H
)
CSL1C003ZU
INPUT RY92 90M-LY000380R 90M-LY000380R RELAY D3023 HSL4C008ZE
PUSH S/W PWB
(
CUP11869Z-5
)
P SW C877
/
N1B 90M-DK100800R 90M-DK100800R CER. CAP. ! DKS471ME KCKDKS471ME
P SW C877
/
N1G 90M-DK100800R 90M-DK100800R CER. CAP. ! DKS471ME KCKDKS471ME
P SW C877
/
N1S 90M-DK100800R 90M-DK100800R CER. CAP. ! DKS471ME KCKDKS471ME
P SW CN88
/
N1B ns
p
ns
p
CONN. 2P WAFER CJP02GA89ZY
P SW CN88
/
N1G ns
p
ns
p
CONN. 2P WAFER CJP02GA89ZY
P SW CN88
/
N1S ns
p
ns
p
CONN. 2P WAFER CJP02GA89ZY
P SW SW97
/
N1B 90M-SP001250R 90M-SP001250R SW ! JPP1197CSA64 KSH1A001ZV
P SW SW97
/
N1G 90M-SP001250R 90M-SP001250R SW ! JPP1197CSA64 KSH1A001ZV
P SW SW97
/
N1S 90M-SP001250R 90M-SP001250R SW ! JPP1197CSA64 KSH1A001ZV
POWER PWB
(
CUP11873Z
)
POWER BK10 ns
p
ns
p
BRACKET BRACKET PWB CMD1A387
POWER BN65 ns
p
ns
p
CORD WIRE ASSY CWB3F006150UZ
POWER BN81 ns
p
ns
p
CORD WIRE ASSY CWB1B906200EN
225
