NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POWER BN82 ns
p
ns
p
CORD WIRE ASSY CWZSR7001BN82
POWER C601 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
POWER C602 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
POWER C603 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
POWER C604 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
POWER C605 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
POWER C606 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
POWER C607 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
POWER C608 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
POWER C609 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
POWER C610 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
POWER C611 ns
p
ns
p
CER. CAP. 1000PF 50V KB CCKT1H102KB
POWER C612 ns
p
ns
p
CER. CAP. 1000PF 50V KB CCKT1H102KB
POWER C613 ns
p
ns
p
CER. CAP. 1000PF 50V KB CCKT1H102KB
POWER C614 ns
p
ns
p
CER. CAP. 1000PF 50V KB CCKT1H102KB
POWER C615 ns
p
ns
p
CER. CAP. 1000PF 50V KB CCKT1H102KB
POWER C616 ns
p
ns
p
CER. CAP. 1000PF 50V KB CCKT1H102KB
POWER C617 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
POWER C618 ns
p
ns
p
CER. CAP. 1000PF 50V KB CCKT1H102KB
POWER C619 ns
p
00MOA10710020 ELECT CAP. 100UF 100V CCEA2AH101E
POWER C620 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
POWER C621 ns
p
00MOA47605020 ELECT CAP. 47UF 50V CCEA1HH470T
POWER C622 ns
p
00MOA47605020 ELECT CAP. 47UF 50V CCEA1HH470T
POWER C623 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
POWER C625 ns
p
ns
p
FILM CAP. 0.1UF 50V ZF CCFT1H104ZF
POWER C626 ns
p
ns
p
FILM CAP. 0.1UF 50V ZF CCFT1H104ZF
POWER C627 ns
p
ns
p
FILM CAP. 0.1UF 50V ZF CCFT1H104ZF
POWER C628 ns
p
ns
p
FILM CAP. 0.1UF 50V ZF CCFT1H104ZF
POWER C629 90M-EB000030R 90M-EB000030R ELECT CAP. ! ELNA LHO SERIES 71V 18000UF CCET71VLHO183R
POWER C630 90M-EB000030R 90M-EB000030R ELECT CAP. ! ELNA LHO SERIES 71V 18000UF CCET71VLHO183R
POWER CN61 ns
p
ns
p
CONN. STRAIGHT, 2PIN CJP02GA01ZY
POWER CN62 ns
p
ns
p
CONN. STRAIGHT, 7PIN CJP07GA01ZY
POWER CN63 ns
p
ns
p
CONN. 5P WAFER YMW025-05R CJP05GA01ZY
POWER CN65 ns
p
ns
p
CONN. 16P WAFER CJP16GA147ZY
POWER CN66 ns
p
ns
p
CONN. 3P STRAIGHT CJP03GA01ZY
POWER CN67 ns
p
ns
p
CONN. A3963WV2-5P
(
3.96MM
)
CJP05GA148ZW
POWER CN68 ns
p
ns
p
CONN. A3963WV2-5P
(
3.96MM
)
CJP05GA148ZW
POWER CN69 90M-YJ003110R 90M-YJ003110R CONN. 7P B TO B HOUSING CJP07GB99ZY
POWER CN90 ns
p
ns
p
CONN. 8P STRAIGHT CJP08GA01ZY
POWER CN92 ns
p
ns
p
CONN. 9P WAFER YMW025-09R CJP09GA01ZY
POWER D601 ns
p
90M-HD201750R DIODE 1N4003 CVD1N4003SRT
POWER D602 ns
p
90M-HD201750R DIODE 1N4003 CVD1N4003SRT
POWER D603 ns
p
90M-HD201750R DIODE 1N4003 CVD1N4003SRT
POWER D604 ns
p
90M-HD201750R DIODE 1N4003 CVD1N4003SRT
POWER D605 ns
p
90M-HD201750R DIODE 1N4003 CVD1N4003SRT
POWER D606 ns
p
90M-HD201750R DIODE 1N4003 CVD1N4003SRT
POWER D613 ns
p
90M-HD201750R DIODE 1N4003 CVD1N4003SRT
POWER D614 90M-HD302360R 90M-HD302360R ZENER DIODE ZJ6.8B 1/2W CVDZJ6.8BT
POWER D615 90M-HD302400R 90M-HD302400R ZENER DIODE ZJ30BT CVDZJ30BT
POWER J590 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
POWER J591 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
POWER J592 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
POWER J593 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
POWER J594 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
POWER J595 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
POWER J596 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
POWER J597 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
POWER J598 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
POWER J599 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
POWER J600 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
POWER J601 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
POWER J602 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
POWER J603 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
POWER J604 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
POWER J605 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
POWER J606 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
POWER J607 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
