Marantz SR8001 - Page 195

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POWER R642 ns
p
ns
p
RES. 100 OHM 1/4W J CRD25TJ101T
POWER R643 ns
p
ns
p
RES. 100 OHM 1/4W J CRD25TJ101T
POWER R644 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473T
POWER R645 ns
p
ns
p
RES. 1.2K OHM 1/5W J CRD20TJ122T
POWER RY61 00MLY20240510 00MLY20240510 RELAY OSA-SS-224DM3 HSL4B017ZU
POWER RY62 00MLY20240490 00MLY20240490 RELAY 5GPA-28 DC24 HSL3B013ZE
POWER RY63 00MLY20240490 00MLY20240490 RELAY 5GPA-28 DC24 HSL3B013ZE
POWER RY64 00MLY20240490 00MLY20240490 RELAY 5GPA-28 DC24 HSL3B013ZE
POWER RY65 00MLY20240490 00MLY20240490 RELAY 5GPA-28 DC24 HSL3B013ZE
POWER RY66 00MLY20240520 00MLY20240520 RELAY ! PCLH-203D1SP HSL4B018ZU
REGULATOR PWB
(
CUP11876Z
)
REG BN61 ns
p
ns
p
CORD WIRE ASSY CWB1D902150BM
REG BN91 ns
p
ns
p
CORD WIRE ASSY CWB1D908180BM
REG BN92 ns
p
ns
p
CORD WIRE ASSY CWB1D909200BM
REG BN94 ns
p
ns
p
CORD WIRE ASSY CWB1D908670BM
REG BN97 ns
p
ns
p
CORD WIRE ASSY CWB1B003050NN
REG C903 00MEA10901670 00MEA10901670 ELECT CAP. 10000UF 16V CCEA1CH103E
REG C904 ns
p
ns
p
FILM CAP. 0.1UF 50V ZF CCFT1H104ZF
REG C905 ns
p
ns
p
FILM CAP. 0.1UF 50V ZF CCFT1H104ZF
REG C906 ns
p
00MOA10702520 ELECT CAP. 100UF 25V CCEA1EH101T
REG C907 00MEA10901670 00MEA10901670 ELECT CAP. 10000UF 16V CCEA1CH103E
REG C908 ns
p
ns
p
FILM CAP. 0.1UF 50V ZF CCFT1H104ZF
REG C909 ns
p
ns
p
FILM CAP. 0.1UF 50V ZF CCFT1H104ZF
REG C910 ns
p
00MOA10702520 ELECT CAP. 100UF 25V CCEA1EH101T
REG C911 90M-EA001180R 90M-EA001180R ELECT CAP. 10000UF 35V CCET35VKL5103NK
REG C912 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
REG C913 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
REG C914 ns
p
00MOA10702520 ELECT CAP. 100UF 25V CCEA1EH101T
REG C915 90M-EA001190R 90M-EA001190R ELECT CAP. 6800UF 35V CCET35VKL5682NK
REG C916 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
REG C917 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
REG C918 ns
p
00MOA10702520 ELECT CAP. 100UF 25V CCEA1EH101T
REG CN92 00MYP04000760 00MYP04000760 CONN. 7.92MM
(
YUNHO
)
CJP02KA060ZY
REG CN93 ns
p
ns
p
CONN. 8P STRAIGHT CJP08GA01ZY
REG CN95 ns
p
ns
p
CONN. 6P STRAIGHT CJP06GA19ZY
REG CN96 ns
p
ns
p
CONN. 5P STRAIGHT CJP05GA19ZY
REG D902 90M-HE200330R 90M-HE200330R DIODE ! BU804F HVDKBU804F
REG D905 90M-HE200330R 90M-HE200330R DIODE ! BU804F HVDKBU804F
REG D906 ns
p
90M-HD201750R DIODE 1N4003 CVD1N4003SRT
REG D907 ns
p
90M-HD201750R DIODE 1N4003 CVD1N4003SRT
REG ET10 ns
p
ns
p
TERMINAL EARTH PLATE CNE75
REG F901 90M-FS001450R 90M-FS001450R FUSE ! T 5A 250V LITTLE FUSE 382 KBA2D5000A2EYT
REG F902 90M-FS001450R 90M-FS001450R FUSE ! T 5A 250V LITTLE FUSE 382 KBA2D5000A2EYT
REG IC91 90M-HC300750R 90M-HC300750R IC KIA378R05PI HVIKIA378R05PI
REG IC92 90M-HC300750R 90M-HC300750R IC KIA378R05PI HVIKIA378R05PI
REG IC93 00MHC3891509F 00MHC3891509F IC NJM7815FA HVINJM7815FA
REG IC94 00MHC3991509F 00MHC3991509F IC NJM7915FA HVINJM7915FA
REG J900 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J901 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J902 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J903 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J904 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J905 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J906 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J907 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J908 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J909 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J910 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J911 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J912 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J913 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J914 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J915 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J916 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J917 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J918 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J920 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
229
