NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
REG J921 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J922 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J923 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J924 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J925 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG J926 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG R903 90M-NH000080R 90M-NH000080R FUSE RES. ! 0.47 OHM 1W J KRQ1AJR47H
REG R904 90M-NH000080R 90M-NH000080R FUSE RES. ! 0.47 OHM 1W J KRQ1AJR47H
REG R906 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223T
REG R907 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223T
REG R908 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
REG R909 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104T
REG R910 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104T
REG TH81 90M-HP000080R 90M-HP000080R VARISTOR PTFM04BD222Q2N34B0 BRTPTFM04BD222Q
RS-232C PWB
(
CUP11874Z-3
)
RS232 BK91 ns
p
ns
p
BRACKET BRACKET FOR PWB CMD1A569
RS232 C901 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
RS232 C902 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
RS232 C903 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
RS232 C904 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
RS232 C905 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
RS232 CN90 ns
p
ns
p
CONN. 00906-0027 4P STRAIGHT CJP04GA19ZY
RS232 J901 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
RS232 J902 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
RS232 JK90 90M-YT005040R 90M-YT005040R TERMINAL 9P D-SUB MALE
(
RS-232C
)
SEMCO CJJ9V001Z
SBLR SPEAKER PWB
(
CUP11874Z-2
)
SBLR BK81 ns
p
ns
p
BRACKET BRACKET FOR PWB CMD1A569
SBLR C810 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
SBLR C811 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
SBLR C812 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
SBLR C813 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
SBLR C814 ns
p
ns
p
CER. CAP. 1000PF 50V KB CCKT1H102KB
SBLR C815 ns
p
ns
p
CER. CAP. 1000PF 50V KB CCKT1H102KB
SBLR C816 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
SBLR C817 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
SBLR CN81 ns
p
ns
p
CONN. 6P STRAIGHT CJP06GA19ZY
SBLR CN82 ns
p
ns
p
CONN. 2P WAFER CJP02GA89ZY
SBLR CN83 ns
p
ns
p
CONN. 2P WAFER CJP02GA89ZY
SBLR D801 ns
p
90M-HD201750R DIODE 1N4003 CVD1N4003SRT
SBLR D802 ns
p
90M-HD201750R DIODE 1N4003 CVD1N4003SRT
SBLR J800 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
SBLR J800
/
U1B ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
SBLR J801 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
SBLR J802 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
SBLR J803 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
SBLR J804 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
SBLR J805 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
SBLR J806 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
SBLR J807 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
SBLR J808 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
SBLR JK80 90M-YT004020R 90M-YT004020R TERMINAL 6P SPEAKER CJJ5Q012Z
SBLR Q801 00MHT600111B0 00MHT600111B0 TRS. KTA1267Y HVTKTA1267YT
SBLR Q802 00MHT600111B0 00MHT600111B0 TRS. KTA1267Y HVTKTA1267YT
SBLR Q803 00MBA20001000 00MBA20001000 TRS. KRC102M HVTKRC102MT
SBLR Q804 00MBA20001000 00MBA20001000 TRS. KRC102M HVTKRC102MT
SBLR R810 ns
p
ns
p
RES. 10 OHM 1W J KRG1SANJ100RT
SBLR R811 ns
p
ns
p
RES. 10 OHM 1W J KRG1SANJ100RT
SBLR R812 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
SBLR R813 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
SBLR R814 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
SBLR R815 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
SBLR R816 ns
p
ns
p
RES. 390 OHM 1W J KRG1SANJ391RT
SBLR R817 ns
p
ns
p
RES. 390 OHM 1W J KRG1SANJ391RT
SBLR R818 ns
p
ns
p
RES. 470 OHM 1W J KRG1SANJ471RT
SBLR R819 ns
p
ns
p
RES. 470 OHM 1W J KRG1SANJ471RT
SBLR RY81 00MLY20240490 00MLY20240490 RELAY 5GPA-28 DC24 HSL3B013ZE
SBLR RY82 00MLY20240490 00MLY20240490 RELAY 5GPA-28 DC24 HSL3B013ZE
230
