NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
VIDEO R756 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
VIDEO R758 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472T
VIDEO R759 ns
p
ns
p
RES. 3.3K OHM 1/5W J CRD20TJ332T
VIDEO R761 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104T
VIDEO R762 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105T
VIDEO R763 ns
p
ns
p
RES. 3.3K OHM 1/5W J CRD20TJ332T
VIDEO R764 ns
p
ns
p
RES. 3.3K OHM 1/5W J CRD20TJ332T
VIDEO R765 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105T
VIDEO R766 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105T
VIDEO R767 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105T
VIDEO R768 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472T
VIDEO R769 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
VIDEO R770 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
VIDEO R771 ns
p
ns
p
RES. 56 OHM 1/5W J CRD20TJ560T
VIDEO R772 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
VIDEO R773 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
VIDEO R774 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
VIDEO R775 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
VIDEO R776 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105T
VIDEO R777 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105T
VIDEO R778 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105T
VIDEO R781 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
VIDEO R782 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
VIDEO R783 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
VIDEO R786 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105T
VIDEO R787 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105T
VIDEO R788 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105T
VIDEO R789 ns
p
ns
p
RES. 75 OHM 1/5W J CRD20TJ750T
VIDEO R790 ns
p
ns
p
RES. 75 OHM 1/5W J CRD20TJ750T
VIDEO R791 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
VIDEO R792 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
VIDEO R793 ns
p
ns
p
RES. 75 OHM 1/5W J CRD20TJ750T
VIDEO R794 ns
p
ns
p
RES. 75 OHM 1/5W J CRD20TJ750T
VIDEO R795 ns
p
ns
p
RES. 3.3K OHM 1/5W J CRD20TJ332T
VIDEO R796 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
VIDEO R797 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
VIDEO R799
/
N1B ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
VIDEO R799
/
N1G ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
VIDEO R799
/
N1S ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
VIDEO R821 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
VIDEO RJ10 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
VIDEO X701 90M-JX001080R 90M-JX001080R X'TAL 14M318 HOX14318D220F
VIDEO X702
/
N1B 90M-JX001090R 90M-JX001090R X'TAL 17M318 HOX17744D220F
VIDEO X702
/
N1G 90M-JX001090R 90M-JX001090R X'TAL 17M318 HOX17744D220F
VIDEO X702
/
N1S 90M-JX001090R 90M-JX001090R X'TAL 17M318 HOX17744D220F
VOLUME PWB
(
CUP11869Z-3
)
VOL BK84 ns
p
ns
p
TERMINAL PLATE EARTH CMC3A111
VOL BK85 ns
p
ns
p
TERMINAL PLATE EARTH CMC3A111
VOL BN12 ns
p
ns
p
CORD WIRE ASSY CWB1B005300EN
VOL BN85 ns
p
ns
p
CORD WIRE ASSY CWZSR7001BN85
VOL C814 ns
p
ns
p
CER. CAP. 100PF 50V K HCBS1H101KBT
VOL C815 ns
p
ns
p
CER. CAP. 100PF 50V K HCBS1H101KBT
VOL C829 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
VOL C830 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
VOL C831 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
VOL C832 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
VOL C833 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
VOL C834 ns
p
ns
p
CER. CAP. 470PF 50V HCBS1H471KBT
VOL C835 ns
p
ns
p
CER. CAP. 470PF 50V HCBS1H471KBT
VOL C836 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
VOL C837 ns
p
ns
p
CER. CAP. 1000PF 50V B HCBS1H102KBT
VOL C838 ns
p
ns
p
CER. CAP. 1000PF 50V B HCBS1H102KBT
VOL C840 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
VOL C846 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
VOL C847 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
VOL C848 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
VOL C852 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
238
