NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
VOL C890 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
VOL CN11 ns
p
ns
p
CONN. ANGLE 7PIN CJP07GB46ZY
VOL CN52 ns
p
ns
p
CONN. STRAIGHT 8PIN CJP08GA19ZY
VOL D805 90M-HI101190R 90M-HI101190R L.E.D. BLUE LED TOL-52CSBBCEAB2 CVD52CSBBCEAB2
VOL EN81 90M-SR000240R 90M-SR000240R ROTARY SW EC16B243040HB HSR2A004Z
VOL IC83 00MHC10053090 00MHC10053090 IC NJM2068DD HVINJM2068DD
VOL IC84 90M-HC108910R 90M-HC108910R IC 74VHC08 HVI74VHC08TTR
VOL J801 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
VOL J803 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
VOL J804 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
VOL J805 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
VOL J842 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
VOL J843 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
VOL J844 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
VOL J871 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
VOL JK83 90M-YT003240R 90M-YT003240R TERMINAL S-TERMINAL 1P CJJ9M004Z
VOL JK84 90M-YT004310R 90M-YT004310R TERMINAL CINCH 3P BLACK GOLDPLATE CJJ4S041Z
VOL JK87 90M-YT005030R 90M-YT005030R OPT. CONN. TORX177L HJSTORX177L
VOL Q813 00MBA10001000 00MBA10001000 TRS. KRA102M HVTKRA102MT
VOL R806 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
VOL R807 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
VOL R808 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
VOL R809 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
VOL R834 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473T
VOL R835 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473T
VOL R836 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473T
VOL R837 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473T
VOL R838 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
VOL R839 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
VOL R841 ns
p
ns
p
RES. 75 OHM 1/5W J CRD20TJ750T
VOL R843 ns
p
ns
p
RES. 75 OHM 1/5W J CRD20TJ750T
VOL R844 ns
p
ns
p
RES. 75 OHM 1/5W J CRD20TJ750T
VOL R851 ns
p
ns
p
RES. 10 OHM 1/5W J CRD20TJ100T
VOL R854 ns
p
ns
p
RES. 220 OHM 1/5W J CRD20TJ221T
VOL R855 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
XM PWB
(
CUP11877Y
)
XM C501
/
U1B ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
XM C502
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V ZF CCUS1H104ZF
XM C503
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V ZF CCUS1H104ZF
XM C504
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V ZF CCUS1H104ZF
XM C505
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V ZF CCUS1H104ZF
XM C506
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V ZF CCUS1H104ZF
XM C507
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V ZF CCUS1H104ZF
XM C508
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V ZF CCUS1H104ZF
XM C509
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V ZF CCUS1H104ZF
XM C510
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V ZF CCUS1H104ZF
XM C511
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V ZF CCUS1H104ZF
XM C514
/
U1B ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC CCUS1H102KC
XM C515
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V ZF CCUS1H104ZF
XM C517
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V ZF CCUS1H104ZF
XM C518
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V ZF CCUS1H104ZF
XM C519
/
U1B ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC CCUS1H102KC
XM C520
/
U1B ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC CCUS1H102KC
XM C521
/
U1B ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC CCUS1H102KC
XM C522
/
U1B ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC CCUS1H102KC
XM C523
/
U1B ns
p
00MDD95220300 CER. CAP. 22PF 50V JA CCUS1H220JA
XM C524
/
U1B ns
p
00MDD95220300 CER. CAP. 22PF 50V JA CCUS1H220JA
XM C601
/
U1B ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC CCUS1H102KC
XM C602
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V ZF CCUS1H104ZF
XM C603
/
U1B ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
XM C604
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V ZF CCUS1H104ZF
XM C605
/
U1B ns
p
00MOA10505020 ELECT CAP. 1UF 50V CCEA1HH1R0T
XM C606
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V ZF CCUS1H104ZF
XM C607
/
U1B ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
XM C611
/
U1B ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
XM C612
/
U1B ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
XM C613
/
U1B ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
