AV receiver
Connecting to an AV receiver with an analog 2-channel audio
input terminal
• This connection is recommended when the specifications of an AV receiver connected to the unit are
as follows:
• Not supporting HDMI input
• Not supporting digital audio(coaxial) input
• Select the connector to use and connect the device.
Cables used for connections
Audio and video cable
Audio and video
cable
(supplied)
R
L
R
L
(White)
(Red)
(Yellow)
Video cable
Component video
cable
(sold separately)
(Green)
(Blue)
(Red)
Connecting an AV receiver
