Marathon Electric DVR 2000E+ - Operating Features

13
4
DVR
®
PROTECTION FUNCTIONS
Features and Protection
Protection
Feature
Congurable Threshold
Range
Threshold
Units
Basis Timer
Range
Timer
Units
Alarm
Code
Fault
Code
Field Over
Excitation
Yes 0.500 - 4.000 A N/A 1.0 - 15.0 S A008 F008
Field Under
Excitation
Yes
-100.0 to
-5.0
%
Rated
Reactive
Power
(kVAR)
1.0 - 15.0 S A002 F002
Generator
Over Voltage
Yes 5.0 - 20.0 %
Voltage
Set Point
0.1 - 15.0 S A013 F013
Generator
Under Voltage
Yes 5.0 - 50.0 %
Voltage
Set Point
1.0 - 15.0 S A012 F012
Generator
Imbalance
Yes 20.0 - 50.0 %
Voltage
Set Point
1.0 - 15.0 S A016 F016
Generator
Loss of
Sensing
No N/A N/A N/A N/A N/A N/A F011
Instantaneous
Field Over
Current
No 11 Adc N/A N/A N/A N/A F009
Regulator
Over
Temperature
No N/A N/A N/A N/A N/A A007 F007
Generator
Reverse
Power
Yes 5.0 - 100.0 %
Rated
Power
(kW)
1.0 - 15.0 S A014 F014
Generator
Start Up
No N/A N/A N/A N/A N/A N/A F004
Generator
Under
Frequency
Yes 40.0 - 70.0 Hz N/A N/A N/A A015 N/A
Field Current
Limiting
Yes 0.5 - 6.5 A N/A N/A N/A A010 N/A
Power
Limiting
Yes 5.0 - 115.0 %
Rated
Power
(kW)
N/A N/A A001 N/A
Loss of CAN Yes N/A N/A N/A 1.0 - 45.0 S A006 N/A
Table 4-1
