36
6
Human-Machine Interface (HMI)
Parameter Name Parameter Value Description
SIZE 281 to 1040
Frame size of generator
REG
AVR3
AVR3 – Voltage regulator with three-phase sensing
AVR1
AVR1 – Voltage regulator with single-phase sensing
FCR
FCR – Field current regulator
VAR
VAR – Reactive VAR regulation (EC+ only)
PF
PF – Power Factor regulation (EC+ only)
STPT
100.0 to 630.0
Voltage set point (Vrms) in AVR3 and AVR1 mode
0.000 to 3.000
Field current set point (Adc) in FCR mode
0.0% to 10.0%
VAR set point (% of rated VAR) in VAR mode. (EC+ only)
0.000 to 0.999
PF set point (PU) in PF mode (EC+ only)
UFRQ 40.0H to 70.0H
Underfrequencyknee(Hz)
DROP 0.0% to 10.0%
Voltage droop (%) at rated reactive power
AU
OFF
Auxiliary Off – Auxiliary input is disabled
CNT1
AuxiliaryControl-1–Auxiliaryinputmodiesregulationsetpoint
(-3 to +3 Vdc input)
SCLF
AuxiliaryMeter–Auxiliaryinputisusedasameterwithuser-dened
scale factor
CNT2
AuxiliaryControl-2–Auxiliaryinputmodiesregulationsetpoint
(4 to 20 mA input)
Table 6-3. DVR
®
HMI EDIT Mode Parameters
