39
Superuser type is intended for Marathon Electric use
only.
Load Factory Settings
When this button is pressed, the default factory
settings for the regulator are loaded into the DVR’s
Random Access Memory (RAM). These factory
settings can be transferred to the user settings
in Electrically Erasable Programmable Read Only
Memory (EEPROM) by pressing the “Save to
EEPROM”button.
Save to EEPROM
When this button is pressed, all parameter values
in the DVR’s RAM (Configuration and Identification
tabs) are transferred to the regulator’s user settings
in EEPROM. These user settings are loaded into
RAM whenever the regulator is powered up.
Load Config
When this button is pressed, the user will be
prompted to select a previously saved .xml file.
When the file is selected, all user-adjustable
settings from the selected .xml file are loaded
into the volatile RAM memory of the DVR
®
. These
settings can be transferred to the user settings
in non-volatile EEPROM by pressing the “Save to
EEPROM”button.
Note: When a file is transferred from a computer to
the regulator, the operating status will switch to “OFF”
and excitation is disabled. To enable excitation with the
new settings, save settings to EEPROM and then click
the “Excitation ON” button on the Operating Modes
sub panel of the Configure tab.
Save Config
When this button is pressed, the user will be
promptedtoselecta.xmlfilename.When the file
isselected,all user adjustable settings presently in
the volatile RAM memory are saved into the selected
.xml file. These settings can be edited and loaded to
the regulator’s volatile RAM memory by pressing the
“LoadConfig”button.
Note: .xml files are text files that can be printed for
reference.
Connect
When this button is pressed, DVRPortal™ estab-
lishes communication with the DVR
®
. Communication
must be established before data can be transferred
between the DVR
®
 and DVRPortal™.When con-
nected,this buttondisplays“Disconnect”to permit
disconnection of communication.
Digital Input Pins (1d)
There are five indicators labeled VAR/PF OFF (EC+
only),DROOPOFF,UP,DOWNandEXCOFFinthe
header. These indicators show the status of the five
input signals to the regulator. If their corresponding
input contacts are closed, they will show as yellow.
If the corresponding input contacts are open, they
will show as gray.
