Offset Display (4d)
This panel displays the offsets contributing to
a modification of the set point for the currently
selected regulation mode.
• Contact Offset displays the effect that the
contact inputs have on the regulator set
point value. Refer to Section 4 – Features and
Protection for a detailed description of the
UPandDOWNcontactinputfunctions.
• Auxiliary Offset displays the effect that the
auxiliary input has on the regulator set point
value. Refer to Section 4 – Features and
Protection for a detailed description of the
Auxiliary Input function.
• Droop Offset displays the effect that the reg-
ulator’s droop function has on the regulator
set point value. Refer to Section 4 – Features
and Protection for a detailed description of
the Load Sharing function.
• CAN Offset displays the effect that the
Set Point Adjust CAN message has on the
regulator set point value. Refer to the
DVR2000E+/EC+ CAN Bus Interface User
Guide for a detailed description of the Set
PointAdjustmessage.
• Step Offset displays the effect that the step
change from the Metering tab has on the
regulator set point value. Refer to Section
4 – Features and Protection for a detailed
description of the step change input func-
tions.
• Total Set Point displays the total reference
to the controller. This reference value is
comprised of the set point and any offsets
currently active.
