MAREX 375
9
by Nikl Design USER MANUAL
2.0 TECHNICAL DATA
Part of the information is given on the builder’s plate fixed on the craft. A full
explanation of this information is given in the relevant sections of this manual.
2.1 GENERAL TECHNICAL DATA
Boat type: Marex 375
Construction category: B
2.2 HULL
Type
Measurement
Unit
Length over all, including bowsprit and platform (LOA)
11,99
m
Length of hull (Lh)
11,90
m
Length hull waterline (LWL)
9,68
m*
Transport height without lantern mast and mounted
extra equipment (Transport height excluding the rudder
and propeller)
3.49
m*
Transport height without lantern mast and mounted
extra equipment (Transport height including the rudder,
propeller and propeller protector)
3.83
m
Total height from bottom to top lantern mast, including
flagpole
4.3
m*
Height from the waterline (Sailing height) with lantern
mast, including flagpole
3.71
m*
Height from the waterline (Sailing height) with lantern
mast, excluding flagpole
3.71
m*
Height from the hulls keel to the top of the lantern mast,
including top lantern
4.3
m
Height of the mounted and removable lantern mast
0.81
m
Marex cradle height
0.10
m
Beam excluding fender list BOA
3.45
m
Beam including fender list BOA
3.49
m
Beam of the boat waterline BWL
3.075
m
Displacement of empty boat (twin engine)
7400
kg *
Maximum recommended load**
2400
kg
Maximum allowed displacement***
9800
kg
- m*/ kg* standard boat and weight with twin engine installation (2 x Volvo D4)
- ** Maximum recommended load includes the weight of all persons onboard, all
provisions and personal effects, any equipment not included in the light craft mass,
cargo (if any) and all consumable liquids (water, fuel, etc.).
- *** see section 2.5 Capacities for detailed loading condition.
