MAREX 375 - Electric System

MAREX 375
39
by Nikl Design USER MANUAL
4.8 ELECTRIC SYSTEM
The system consists of two main parts:
- 12 Volt Direct Current (DC) from the service batteries
- 230 Volt Alternating Current (AC) by the use of shore power. Be aware that you do not
have unlimited power capacity. Use the power carefully and turn off the light in unused
rooms.
Voltage:
12V DC/230V AC
Starter battery:
2x100Ah (Service switch marked “START”)
Service batteries:
4x95Ah (Service switch marked “SERVICE”)
Battery charger:
230V AC
(Optional: AGM battery – starter battery 2x100 Ah, service batteries 4x95 Ah)
Picture 27: Starter batteries (1)
Service batteries (2)
Picture 28: Service batteries (3)
1
2
3
