MAREX 375 - Lensing System; Manual Lensing System; Automatic Lensing System

MAREX 375
32
by Nikl Design USER MANUAL
4.5 LENSING SYSTEM
WARNING:
The bilge pumping system is not designed for damage control.
4.5.1 MANUAL LENSING SYSTEM
The boat has two manual lensing pumps:
▪ One is placed under the hallway floor in the front cabin area (front area).
▪ Second manual pump is placed in the engine room (aft area).
Picture 17: Manual bilge pump for the engine room (1)
The manual lensing system pumps out the water by hand. This system is standard and
is operable from within the designated area. Stick the “pin” (a steel rod with a black
handgrip) and pump up and down. The lens pump is pumping water out of the room
in the direction of the pointed arrow.
4.5.2 AUTOMATIC LENSING SYSTEM
WARNING:
Automatic lens pump does not replace a visual control and it does not work if the
batteries have a lower voltage than 11 Volts.
▪ The automatic lensing system works for cabins, and the engine room.
