POWER TRIM
Page 5B-6 90-855347R1 JANUARY 1999
Power Trim Motor
1
2
3
3
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb.in. lb.ft. N·m
– 1 POWER TRIM MOTOR
1 1 BRUSH AND SEAL KIT
2 1 ARMATURE KIT
3 1 END FRAME (Complete)
