Model ESM301 / ESM301L Test Stand User’s Guide
11
4.4 Upper and Lower Dwell Times (U DWELL and LO DWELL)
This setting corresponds to the amount of time, in seconds, for which the crosshead stops at the limit
during a cycle sequence.
Note:
The dwell time setting is unavailable for an auto return sequence.
Default setting: 0 (no dwell time)
Available settings: 0 – 9999.9
Label Description
+
Increases dwell time in increments of .1. Holding down + will increment at an
increasingly faster rate. If 9999.9 is reached the next number will be 0 and
continue incrementing.
–
Decreases dwell time in increments of .1. Holding down – will decrement at
an increasingly faster rate. If 0 is reached the next number will be 9999.9
and continue decrementing.
ENTR
Returns to the Test Feature Setup menu
ESC
Exits the feature without saving changes
4.5 Upper and Lower Travel Limits (UPPER LM and LOWER LM)
This setting corresponds to the travel distance the crosshead moves before stopping or cycling. Upper
and lower limits are programmed individually. The programmed distances are relative to the zero position
of the crosshead. The travel indicator can be zeroed by pressing and holding STOP for 3 seconds.
Default settings: +12.000 in, -12.000 in (ESM301) or +19.000 in., -19.000 in (ESM301L)
Available settings: From -19.000 to +19.000 in
C Y C L E S : 0 0 0 0 0
E S C − + E N T R
Label Description
+
Increases the number of cycles in increments of 1. Holding down +
will increment at an increasingly faster rate. If 99999 is reached
the next number will be 00000 and continue incrementing.
–
Decreases the number of cycles in increments of 1. Holding down
– will decrement at an increasingly faster rate. If 00000 is reached
the next number will be 99999 and continue decrementing.
Press and hold
+ and –
simultaneously
If pressed and held for 2 seconds or longer the number of cycles
will change to 0.
ENTR
Returns to the Test Feature Setup menu
ESC
Exits the feature without saving changes
H I D
W
E L L : 0 0 0 0 . 0
E S C − + E N T R
H I L I M I T : 2 . 0 5 8
E S C − + E N T R
