Model ESM301 / ESM301L Test Stand User’s Guide
3
1 OVERVIEW
1.1 List of included items
Qty. Description
1 ESM301 or ESM301L test stand
4 Force gauge mounting thumbscrews
2 Limit switch thumbscrews (same as above, supplied in a separate package)
1 Power cord
1 Cable, controller to test frame 12” (longer cables are optional)
1 Cable, USB to RJ11 (for travel indication option)
1 ESM301-002-X column extension (optional)
1 ESM301-003 bench mounting kit (optional)
1 09-1162 multi-function cable (optional)
1 09-1056 serial cable (optional)
1 RSU100 USB converter (optional)
1 Accessories kit (small hook, medium hook, 2” diameter compression plate, 2” extension
rod, #10-32 coupler, Allen wrench set)
1 Resource CD
Note: Unless otherwise indicated, all references to the model ESM301 also apply to the ESM301L.
1.2 Physical Features
Note the following physical features of the ESM301. The user’s guide will reference this terminology.
Limit switches
(rear of column,
not visible)
Force gauge
Upper grip
Lower grip
Controller
Base
Column
Motor
Crosshead
