Model ESM301 / ESM301L Test Stand User’s Guide
2
Thank you…
Thank you for purchasing a Mark-10 ESM301 / ESM301L Force Test Stand,
designed for producing up to 300 lbF (1.5 kN) of tension or compression force.
The ESM301 is an essential component of a force testing system, typically also
comprising a force gauge and grips.
With proper usage, we are confident that you will get many years of great service
with this product. Mark-10 test stands are ruggedly built for many years of service
in laboratory and industrial environments.
This User’s Guide provides setup, safety, and operation instructions. Dimensions
and specifications are also provided. For additional information or answers to your
questions, please do not hesitate to contact us. Our technical support and
engineering teams are eager to assist you.
Before use, each person who is to use the test stand should be fully trained
in appropriate operation and safety procedures.
TABLE OF CONTENTS
OVERVIEW .......................................................................................... 3
SETUP AND SAFETY ......................................................................... 4
OPERATION BASICS ......................................................................... 6
TEST FEATURE SETUP ............................................ …………………8
OPERATING MODES ........................................................................ 18
COMMUNICATION ............................................................................ 23
FUNCTION ACTIVATION .................................................................. 25
TROUBLESHOOTING ....................................................................... 27
MAINTENANCE AND SERVICE ....................................................... 28
SPECIFICATIONS ............................................................................. 29
DIMENSIONS .................................................................................... 29
