Model ESM301 / ESM301L Test Stand User’s Guide
8
DEMO MODE
The ESM301 is shipped in Demo Mode, during which time all available functions are
temporarily activated for 160 hours of operation. At power-up, a counter displays the
number of hours remaining, as follows:
Press STOP to continue.
At the end of this period, any functions not originally purchased will be deactivated,
and will no longer be accessible from the Test Feature Setup menu. Demo Mode
can be suspended at any time by pressing and holding STOP while turning on power
to the test stand. This mode can be re-enabled in the same manner, and will be
active for the remaining time period.
Refer to the Function Activation section for instructions for field activation.
R E MA I N I N G DEMO
T I ME : 1 6 0 H
O
UR S
4 TEST FEATURE SETUP
This section provides configuration instructions for each test feature.
Feature Standard / Optional
Speed (same for both directions) Standard
Independent up and down speeds Optional
Auto return Optional
Cycling with dwell time Optional
Programmable travel limits Optional
Overload protection Optional
Preload Optional
Load Holding Optional
Break Detection Optional
PC control Optional
Communication settings Standard
Units of speed Standard
Programmable button configuration Standard
Password protection Standard
All ESM301 test stands are shipped in Demo Mode, as explained in the Overview section. After Demo
Mode expires, only installed functions will be displayed in Test Feature Setup. The initial Test Feature
Setup screen appears as follows:
S P E E D : 1 0 . 0 0
E S C < − − > E N T R
