Model WT3-201 Wire Crimp Pull Tester User’s Guide
11
If tones are enabled, a tone will sound when the output, storage, and zero functions have occurred.
9.2 Break Settings
Select Break Settings from the Break Detection menu to configure the settings. The display appears as
follows:
9.3 Auto Output Settings
Scroll to Auto Settings in the Break Detection menu and press ENTER to configure the auto output
settings. Any combination may be selected. The display appears as follows:
Parameter Description
RS232/USB Output
Automatically output the peak when the break (% Drop) is detected.
Mitutoyo Output
Automatically output the peak when the break (% Drop) is detected.
Output Pin
Automatically toggle the SP1, SP2, or SP3 pins (active low). If not required, select
“NONE”.
10 DATA MEMORY AND STATISTICS
The WT3-201 has storage capacity of 1,000 data points. Readings may be stored, viewed, and output to
an external device. Individual, or all, data points may be deleted. Statistics are calculated for the data
presently in memory.
To enable memory storage, select DATA Key from the menu, then scroll to Memory Storage and press
ENTER. Then exit the menu. In the home screen, the data record number 0000 appears below the
primary reading. Press DATA at any time to save the displayed reading. The record number will
Threshold
Sets the percentage of full scale at which the break detection function becomes
active. This threshold is provided to ignore peaks that can occur during sample
loading and unloading.
Available settings: –90%, in 1% increments until 5%, 5% increments thereafter.
% Drop
Sets the percentage drop from the peak reading at which the break is detected.
Available settings: 5%–90% in 5% increments.
Auto Zero Delay
Sets the time delay before the primary and peak readings are zeroed. Auto zero
can be disabled if required. Refer to the Auto Output Settings sub-section for
details. Available settings: 1–10 sec. in 1 sec. increments, and 10–60 sec. in 5 sec.
increments.
BREAK DETECTION
SETTINGS
Threshold: 5 %
% Drop: 50 %
Auto Zero Delay
5 sec.
AUTO OUTPUT
SETTINGS
RS232/USB Output
Mitutoyo Output
Output Pin: NONE
