Model WT3-201 Wire Crimp Pull Tester User’s Guide
13
For output of data and/or statistics, RS-232 or USB output must be enabled. Data formatting is
<CR><LF> following each value. Units can be either included or excluded. Output of data via the Mitutoyo
output is possible, however, output of statistics is not. Refer to the Communications and Outputs
section for details.
Note: Data is not retained while the gauge is powered off. However, the gauge protects against
accidental or automatic power-off. If manually powering the instrument off, or if the inactivity time limit for
the Automatic Shutoff function has been reached, the following warning message appears:
If no option is selected, this screen will be displayed indefinitely, or until battery power has been depleted.
11 COMMUNICATIONS AND OUTPUTS
Communication with the WT3-201 tester is achieved through the micro USB or 15-pin serial ports, as
shown in the illustration in the Power section. Communication is possible only when the tester is in the
main operating screen (i.e. not in a menu or configuration area).
11.1 Serial / USB
To set up RS-232 and USB communication, select Serial/USB Settings from the menu. The display
appears as follows:
Select either RS-232 or USB input (output is always simultaneous through both the USB and RS-232
ports). Communication settings are permanently set to the following:
Data Bits: 8
Stop Bits: 1
Parity: None
Other settings are configured as follows:
11.1.1 Baud Rate
Select the baud rate as required for the application. It must be set to the same value as the receiving
device.
11.1.2 Data Format
Select the desired data format. The display appears as follows:
SERIAL/USB SETTINGS
* RS232 Selected
USB Selected
+ Baud Rate
+ Data Format
*** WARNING ***
DATA IN MEMORY
WILL BE LOST
CANCEL
POWER OFF
