Model WT3-201 Wire Crimp Pull Tester User’s Guide
23
14.7 Information / Welcome Screen
The following screen is displayed at power up and can be accessed at any time by selecting Information
from the menu:
15 SPECIFICATIONS
15.1 General
Force Capacity:
200 x 0.1 lbF | 3200 x 2 ozF | 100 x 0.05 kgF | 1000 x 0.5 N | 1 x 0.0005 kN
Accuracy:
±0.2% of full scale
Wire diameter range:
AWG30 - AWG 3 [0.01 - 0.25 in (0.3 - 6.3 mm)]
Min. sample length:
6.50 in [165 mm], excluding termination
Max. elongation:
1.15 in [29.2 mm]
Sampling rate:
7,000 Hz
Power:
AC or rechargeable battery. Low battery indicator appears when battery level is low, and
tester powers off automatically when power reaches critical stage.
Battery life:
Backlight on:
up to 7 hours of continuous use
Backlight off:
up to 24 hours of continuous use
Outputs:
USB / RS-232:
Fully configurable up to 115,200 baud. Includes Tester Control Language
2 for full computer control.
Mitutoyo (Digimatic):
Serial BCD suitable for all Mitutoyo SPC-compatible devices.
Analog:
±1 VDC, ±0.25% of full scale at capacity,
General purpose:
Three open drain outputs, one input.
Set points:
Three open drain lines.
Safe overload:
150% of full scale (display shows “OVER” at 110% and above)
Weight:
16.1 lb [7.3 kg]
Included accessories:
Universal voltage AC adapter, battery, quick-start guide, USB cable, resource CD (USB
driver, MESUR
TM
Lite software, MESUR
TM
gauge DEMO software, and user’s guide), and
NIST-traceable certificate of calibration with data.
Environmental
requirements:
40 - 100°F, max. 93% humidity, non-condensating
Warranty:
3 years (see individual statement for further details)
Wire Terminal Tester
Series WT3
Model No: WT3-201
Serial No: 1234567
Version: 1.0
(c) Mark-10 Corp.
