Model WT3-201 Wire Crimp Pull Tester User’s Guide
21
14 OTHER SETTINGS
14.1 Automatic Shutoff
The tester may be configured to automatically power off following a period of inactivity while on battery
power. Inactivity is defined as the absence of any key presses or load changes of 100 counts or less. To
access these settings, select Automatic Shutoff from the menu. The display appears as follows:
Select Disabled to disable automatic shutoff. Select Enabled to enable it. The length of time of inactivity
is programmed in minutes via the Set Minutes parameter. Available settings: 5-30, in 5 minute
increments.
Note: If the AC adapter is plugged in, the tester will ignore these settings and remain powered on until the
POWER key is pressed.
14.2 Backlight
Although the backlight may be turned on and off at any time by pressing the BACKLIGHT key, there are
several available initial settings (applicable upon powering on the tester). To access these settings, select
Backlight from the menu. The display appears as follows:
Selection Description
Off
Backlight to be off upon powering on the tester.
On
Backlight to be on upon powering on the tester.
Auto
Backlight to be on upon powering tester, but will shut off after a period of inactivity (as
defined in the Automatic Shutoff sub-section). The backlight will turn on again when
activity resumes. The length of time of inactivity is programmed in minutes via the Set
Minutes parameter. Available settings: 1-10, in 1 minute increments.
Note: If the AC adapter is plugged in, the tester will ignore these settings and keep the backlight on,
unless the BACKLIGHT key is pressed. Selecting the On or Off setting in the Backlight menu will
manually turn the backlight on or off as if the Backlight button were pressed.
14.3 LCD Contrast
The contrast of the display may be adjusted. Select LCD Contrast from the menu. The screen appears
as follows:
BACKLIGHT
Off
On
* Auto
Set Minutes
1
AUTOMATIC SHUTOFF
* Disabled
Enabled
Set Minutes
5
