Model WT3-201 Wire Crimp Pull Tester User’s Guide
17
5. Place the tester horizontally on a level surface free from vibration, then press ZERO. The tester
will calculate offsets, and the display appears as follows:
If failed:
6. The following screen appears after the offsets have been calculated:
Attach weight fixtures (brackets, hooks, etc), as required. Do not yet attach any weights or apply
any calibration loads. Then press ENTER.
7. The display appears as follows:
Optionally exercise the load cell several times (at full scale, if possible), then press ENTER.
8. The display appears as follows:
CALIBRATION
Attach necessary
weight fixtures,
then press ENTER.
CALIBRATION
Optionally exercise
sensor, then press
ENTER.
CALIBRATION
OFFSET
Sensor failed
Analog failed
CALIBRATION
OFFSET
Sensor passed
Analog passed
CALIBRATION
OFFSET
Please wait…
CALIBRATION
OFFSET
Place force tester
horizontal, then
press ZERO.
