2-6
Basic Operation Mark Levinson
10. communication ports
11. IR input connector
12. trigger input / trigger output connectors
13. N°25/S DC power connector
14. ac mains connector
15. earth ground connector
Below are descriptions of the connectors and ports listed above.
DC power connectors
Allow the Controller to provide DC power to the preamplifier using
the supplied DC power connectors. Two DC power connectors
labeled left-channel and right-channel DC power are available on
the Controller, and two DC power connectors labeled DC power are
available on the preamplifier.
1. Using one of the supplied DC power cables, connect the Con-
troller left-channel DC power connector to the preamplifier
left-channel DC power connector.
Note DC power cables are not directional.
2. Using the other DC power cable, connect the Controller right-
channel DC power connector to the preamplifier right-channel
DC power connector.
