Mark Levinson 32 - Gain Resolution; Input Overload; Input Impedance; Output Impedance

A-2
Appendix Mark Levinson
Gain Resolution
1.0dB increments up to 23.0dB in display (-57dB to -80dB)
0.1dB increments above 23.0dB in display (0dB to -57dB)
Input Overload
Input Impedance
100kΩ
Output Impedance
<10Ω on balanced (XLR)
<20Ω on unbalanced (RCA)
Maximum Main
Output
16V on balanced (XLR)
8V on unbalanced (RCA)
THD + N
<0.001% balanced
Crosstalk
<120dB (any input to any output, input unterminated)
<140dB (any input to any output, input terminated)
Residual Noise
<120dB (20Hz to 20kHz, input terminated) balanced
Frequency Response
10Hz to 40kHz (±0.2dB)
Overall Dimensions
See “Nº32 Controller Dimensions” on page A-4 and “Nº32 Pream-
plifier Dimensions” on page A-5
Shipping Weight
Controller: 60 pounds (27kg)
Preamplifier: 46 pounds (21kg)
All specifications are subject to change without notice.
Gain XLR Inputs RCA Inputs
+18dB 2V 1V
+12dB 4V 2V
+6dB 8V 4V
0dB 16V 8V
