Mark Levinson 32 - Section 3: Setup Menu; Setup Menu Navigation

3-1
Setup Menu Navigation
Figure 3-1: Mapping of the one-line front panel Setup Menu displays
VOLUME UP
VOLUME DOWN
SELECT NEXT
SELECT PREV
INTENSITY
MUTE KEY
MONO KEY
POLARITY KEY
STANDBY KEY
ENTER KEY
SETUP KEY
BALANCE KEY
RECORD KEY
EXIT STANDBY
GO STANDBY
GO INPUT 1
GO INPUT 2
GO INPUT 3
GO INPUT 4
GO INPUT 5
GO INPUT 6
GO INPUT 7
GO INPUT 8
GO PHONO 1
GO PHONO 2
GO MUTE
GO UNMUTE
GO MONITOR
GO RECORD
GO BALANCE
EXIT BALANCE
DISPLAY OFF
DISPLAY DIM
DISPLAY HALF
DISPLAY FULL
Set Input 1
Set Input 2
Set Input 3
Set Input 4
Set Input 5
Set Input 6
Set Input 7
Set Input 8
Name=INPUT 4
Gain= +12 dB
Offset= 0.0
Rec.Out=NONE
Name=INPUT 8
Gain= +12 dB
Offset= 0.0
Rec.Out=NONE
-80.0 TO -10.0 40.0 TO 80.0 12v,L
5v,P
Name=INPUT 3
Gain= +6 dB
Offset= 0.0
Rec.Out=NONE
Name=INPUT 2
Gain= +6 dB
Offset= 0.0
Rec.Out=NONE
Name=INPUT 1
Gain= +6 dB
Offset= 0.0
Rec.Out=NONE
NONE
#1
#2
#3
0 dB
+6 dB
+12dB
+18dB
-20.0 to +20.0
Name=INPUT 7
Gain= +12 dB
Offset= 0.0
Rec.Out=NONE
Name=INPUT 6
Gain= +12 dB
Offset= 0.0
Rec.Out=NONE
Name=INPUT 5
Gain= +12 dB
Offset= 0.0
Rec.Out=NONE
Input names can be
customized using
the Custom Names
List or Character
List.
No32 Setup
Set Inputs
Teach IR
Mute = -20.0
MaxVol= 80.0
Trig.= 12v,L
Sw 1.08 1.06
Setup Menu
