Mark Levinson 32 - Nº32 Controller Dimensions

A-4
Nº32 Controller Dimensions
Figure A-1: Controller front view.
Figure A-2: Controller top view.
power
select
record out
polarity
display intensity setup
enter balance mute
mono
volume
standby
REFERENCE CONTROLLER
Nº32
19.5"
(49.5 cm)
15.75"
(40.01 cm)
0.275"
(0.699 cm)
2.75"
(6.99 cm)
1.875"
(4.76 cm)
1.862"
(4.73 cm)
3.03"
(7.68 cm)
19.5"
(49.5 cm)
9.525"
(24.19 cm)
4.025"
(10.22 cm)
1.58"
(4.01 cm)
5.95"
(15..11 cm)
7.675"
(19.49 cm)
11.375"
(28.89 cm)
2.0"
(5.08 cm)
1.7"
(4.32 cm)
