A-1
Specifications
Power Consumption
65W maximum
Operating Voltage
100V, 120V, 220V, 230V, or 240VAC @ 50 or 60Hz (preset)
Preamplifier
Connectors
3 balanced stereo inputs (female XLR)
5 unbalanced stereo inputs (RCA)
2 balanced main stereo outputs (male XLR)
2 unbalanced main stereo outputs (RCA)
1 balanced record stereo output (male XLR)
2 unbalanced record stereo outputs (RCA)
1 phono ground terminal
2 DC power connectors
Controller Connectors
1 IEC-standard AC mains receptacle
1 ir input (1/8-inch/3.5mm mini-jack)
1 trigger input (1/8-inch/3.5mm mini-jack)
1 trigger output (1/8-inch/3.5mm mini-jack)
3 Link communication ports (RJ-45)
1 RS-232 port (RJ-11)
2 control ports (RJ-45)
1 earth-reference ground terminal
2 DC power connectors
Gain
0, +6, +12, or +18dB (line-level stage)
Volume Control Range
80.0dB
Appendix
