Mark Levinson 32 - Index

I-1
A
ac mains connector, 2-6, 2-9
access panels
phono module, 2-8
B
balance button, 2-2, 2-4, 2-11, 2-
12, 4-3
balance LED, 2-2, 2-4
balanced input connectors, 2-5, 2-
7
C
channel balance, 4-5
communication ports, 2-6, 2-8
connectors
ac mains, 2-6, 2-9
balanced input, 2-5, 2-7
DC power, 2-5, 2-6
earth ground, 2-6, 2-10
IR input, 2-6, 2-9
main output, 2-5, 2-7
Nº25/S DC power, 2-6, 2-9
phono ground, 2-5, 2-8
record output, 2-5, 2-7
trigger input, 2-6, 2-9
unbalanced input, 2-5, 2-7
control ports, 2-5, 2-8
controller connectors, A-1
controller display. See front panel
display
crosstalk, A-2
D
DC power connectors, 2-5, 2-6
default settings, 5-4, 5-4
display button, 2-11, 2-12
display intensity button, 2-2, 2-4,
4-2
dual-mono design, 1-2
E
earth ground connector, 2-6, 2-10
earth-reference ground, 2-8
enter button, 2-2, 2-4, 2-11, 2-12
EQ (equalizer) mode, 4-7
F
frequency response, A-2
front panel controls
balance button, 2-2, 2-4
display intensity button, 2-2,
2-4
enter button, 2-2, 2-4
mute button, 2-2, 2-4
power button, 2-1, 2-2
record out button, 2-1, 2-4
select knob, 2-1, 2-2
setup button, 2-2, 2-4
standby button, 2-1, 2-2
volume knob, 2-1, 2-3
front panel display, 2-1, 2-3
front panel indicators
balance LED, 2-2, 2-4
mono LED, 2-1, 2-3
mute LED, 2-2, 2-4
polarity LED, 2-1, 2-3
preamplifier LED, 2-1, 2-2
record out LED, 2-1, 2-4
setup LED, 2-2, 2-4
G
gain, A-1
gain input parameter, 3-3, 3-7
gain levels, 3-3
gain resolution, A-2
I
IEC-standard, 2-9
input impedance, A-2
input overload, A-2
installation worksheet, A-6
IR input connector, 2-6, 2-9
IR transmitter, 2-11
IR transmitter LED, 2-11
isopropyl alcohol, 5-5
L
link cables, 4-14
link communication ports, 4-13
link controls, 4-18
M
main output connectors, 2-5, 2-7
maintenance, 5-4
master volume level, 3-10
maximum main output, A-2
maxvol parameter, 3-10
mini-jack, 2-9
mono button, 2-11, 2-12
mono LED, 2-1, 2-3
mono playback mode, 4-4
mute button, 2-2, 2-4, 2-11, 2-12
mute LED, 2-2, 2-4
mute level, 3-10
mute parameter, 3-10
N
name (an input) parameter, 3-3,
3-4
Nº25/S DC power connector, 2-6,
2-9
O
offset input parameter, 3-3, 3-7
operating voltage, A-1
output impedance, A-2
overall dimensions, A-2
P
phono ground connector, 2-5, 2-8
phono module access panels, 2-5,
2-8
polarity button, 2-11, 2-12, 4-2
polarity LED, 2-1, 2-3
ports
communication, 2-6, 2-8
control, 2-5, 2-8
RS-232, 2-5, 2-8
power button, 2-1, 2-2
power consumption, A-1
power cord, 5-1
preamplifier connectors, A-1
preamplifier LED, 2-1, 2-2
R
rec. out input parameter, 3-3, 3-7
record mode, 4-7
record out button, 2-1, 2-4
record out LED, 2-1, 2-4
record output connectors, 2-5, 2-7
remote control
balance button, 2-11, 2-12
batteries, 1-6
display button, 2-11, 2-12
enter button, 2-11, 2-12
Index
