17
S88 Pin Name Description PIN RJ45
Color
EIA/TIA 568A
1 DATA Readout Data 2 green
2 GND Ground for signals and voltage supply 3 white/ orange
2 GND 5 white/blue
3 CLOCK Clock signal for the synchronization 4 blue
4 PS (LOAD) Load the data into the bus 6 orange
5 RESET Reset the input memory 7 white/brown
6 +5V/+12V Voltage supply for the feedback module 1 white/green
— SHIELD Cable shield, not connected — —
PIN Assignment for the RJ45 Plug
Märklin assumes no liability for joint use of Märklin products and products of other makes.
We therefore urgently recommend that you check the PIN assignments of the RJ45 plug you may be using.
Current Supply:
5volts in mixed operation of S88 and S88 AC/DC Märklin products (as shown in the illustration), as well as products of other
makes.
12 volts only in conjunction with the S88 AC/DC. The susceptibility to interruptions is reduced with a 12 volt power supply.
