Red/White Park Light Relay Input
Black Chassis Ground
Brown (-) Programmable Output (Horn - Default)
White Parking Light Relay Output
Red +12VDC Battery Input
HC3 3-Pin Door Lock Harness
Green (-) Lock Output
Blue (-) Unlock Output
5
Wiring Harness Quick Reference
Violet/White Tach Input
Gray (-) Remote Start Hood Pin Safety Input
Brown (+) Brake Switch Input
Black/White (-) Neutral Safety Switch Input
HC4 9-Pin Accessory Harness
Pink (-) Ignition #3 Output
White/Blue AUX Start and Turn Off Input
White (-) Programmable Output (Dome Lt - Default)
Red/White (-) Channel #3 Output (Trunk Release)
Light Blue (-) Programmable Output (2nd Unlock Ouput)
