Product Description
Triplematic
14 Triplematic 201708 EN
3.8 Technical data
Parameter Value
Supply voltage 12-15 V DC
Power 144 W
Current 12 A
Over-current protection Automatic fuse type ptc
Rotation speed 3250 rpm
Peripheral speed 25 m/s
Grinding wheel dimensions
(for the grinding wheels included in the
delivery)
Outer diameter (OD) × Width (W) × Inner diameter (ID):
• 150 mm x 3.2 mm x 16 mm (5 7/8” x 1/8” x 5/8”)
• 150 mm x 4.8 mm x 16 mm ( 5 7/8” x 3/16” x 5/8”)
Max dimensions for the
Triplematic Auto Chain Grinder
Length (L) x Width (W) x Height (H):
480 mm x 330 mm x 520 mm (18.9” x 12.9” x 20.4”)
Dimensions, stand Length (L) x Width (W) x Height (H):
345 mm x 360 mm x 1070 mm (13.5” x 14.1” x 42.1” )
Weight of the machine 17.5 kg
Weight, stand 33 kg
Compressed air supply pressure 5-8 bar
