Accessories and Spare Parts
Triplematic
42 Triplematic 201708 EN
8 Accessories and Spare Parts
8.1 Ordering information
Contact your regional sales representative to order spare parts or accessories. Contact information to the
manufacturer is located on the back cover of this user manual.
8.2 List of accessories
Accessory Description Order Number
Profile stone Stone for profiling ceramic grinding wheels. 12-023
Cleaning stone for CBN wheels Use this cleaning stone to remove dirt and
residues from the CBN wheel.
108
Profile template Template show how to profile the grinding
wheel for different chain types.
12-024
Air tension extension Shorter chains – smaller than 40 drive links –
require this extension to properly engage the
tensioning system.
14-600B
Telescopic chain extension kit For extra long (.404 & 3/4") harvester chains,
our telescopic extension is an ideal choice.
It accommodates up to 4.5 m (14.5 ft) chain
loops.
14-600C
Chain weight Used to tension chain when machine is not
mounted on the stand with air tensioner.
760 (1.5kg chain weight)
860 (2kg chain weight)
Exhaust pipe Metal nozzle with hose attached to the
grinding head. Connect to vacuum cleaner
(not included).
808
Air cooling kit Cools the chain during sharpening, to protect
the metal in the cutting teeth from loosing
their strength. An air cooler allows sharpening
at higher speeds. The air cooler uses
compressed air to cool the chain.
14-700
Grinding wheels Dimensions (OD x W x ID) Order Number
Chain weight Used to tension chain when machine is not
mounted on the stand with air tensioner.
760 (1.5kg chain weight)
860 (2kg chain weight)
Ceramic grinding wheels: 150 mm x 3.2 mm x 16 mm
(5 7/8” x 1/8” 5/8”)
754OR
150 mm x 4.8 mm x 16 mm
(5 7/8” x 3/16” 5/8”)
781MPG
150 mm x 6.4 mm x 16 mm
(5 7/8” x 1/4” 5/8”)
782MPG
150 mm x 8 mm x 16 mm
(5 7/8” x 5/16” 5/8”)
775OR
150 mm x 10 mm 16 mm
(5 7/8” x 3/8” 5/8”)
774OR
