Triplematic
Triplematic 201708 EN 37
Maintenance and Service
7. Do a sharpening test and make sure that the
chain remains in its position during the test.
See section 8.2, “Sharpening test”.
8. If required: Repeat steps 3-8 until the chain is
fixed during sharpening.
6.6 Check and adjust the wire
Note: If the wire is not correctly set, the grinding
machine will not operate correctly. The manufacturer
initially sets the wire, but it will become worn during
normal machine operations. Always make sure
that the wire is set correctly. If necessary, adjust or
replace the wire.
1. Press the power button to turn on the machine.
2. Set the grinding speed knob to high speed. See
section 4.6.2, “Grinding speed knob”.
3. Press the grinding head positioning button to
turn the grinding head to the left.
4. Set the top-plate angle to 30°. See section
6.2.3, “Set the top-plate angle”.
5. Set the chain pusher switch to ON.
