4.4 Assembling the stand
CAUTION The Triplematic Auto Chain Grinder machine must always be attached to the stand. Make sure that
it is safely attached.
1. To mount the grinder on the stand, begin by assembling the stand.
2. The stand comes in 4 pieces: two sides, one base and one front piece.
A
2x
B
1x
C
1x
D
2x
E
2x
I
2x
F
3x
J
7x
G
12x
K
3x
H
4x
L
2x
