Marquette Hellige GmbH MicroSmart V 2.xx Page 35
Servicing Instructions 227 470 35 B - 97.12
3.5 External interfaces
MicroSmart has only three interfaces to the outside:
- Line inlet
- Patient input
3.5.1 Line inlet
The interface of the line inlet has been implemented in the unit by a 3-pin, standardized
connector for non-heating appliances. Line connection via a 3-pin line cable with protective
conductor.
Plug designation:
D/
3.5.2 Patient input
Patient input
and plug of the patient lead have been redesigned because the MicroSmart
guarantees the required defibrillation protection only in connection with the patient lead. This
means that all previously used patient leads
can no longer be used. This also applies to the
suction system with integrated pump.
Plug designation:
AF/
Sub-D socket casing, 15-pin
The function of the individual pins is shown in the following table. The definition in terms of
input/output is as seen from the PCB MicroSmart (patient input).
PinNo. I/O Designation Function
1 Input C2 Input electrode C2
2 Input C3 Input electrode C3
3 Input C4 Input electrode C4
4 Input C5 Input electrode C5
5 Input C6 Input electrode C6
6 Output S Screen
