Marquette Hellige GmbH MicroSmart V 2.xx Page 45
Servicing Instructions 227 470 35 B - 97.12
German, English, French. Default (works) setting the notation
(electrode labels) is AAMI. Otherwise as type "International"
5.2 Selecting the type of appliance
The following procedure is required to select the type of appliance:
- switch off the unit
- switch on the unit while holding the key combination for "delete Configuration" down
(see table below)
- the unit signals Config cleared
- switch off the unit
- switch on the unit while holding the key combination for the type of appliance down.
Key codes for selecting the type of appliance
Key combination Appliance type
BEEP + 5mm/mV delete Configuration (EEPROM )
BEEP + 50mm/s International
BEEP + 25mm/s USA
BEEP + 5mm/s USA2
BEEP + 20mm/mV ASIA
Explanatory notes:
BEEP: loudspeaker key
5mm/mV: sensitivity key 5mm/mV
20mm/mV: sensitivity key 20mm/mV
50mm/s: speed key 50mm/s
25mm/s: speed key 25mm/s
5mm/s: speed key 5mm/s
