Marquette Hellige GmbH MicroSmart V 2.xx Page 36
Servicing Instructions 227 470 35 B - 97.12
7 --- NC ---
8 Input PL Label of patient lead used
9 Input R Input electrode R
10 Input L Input electrode L
11 Input F Input electrode F
12 Input C1 Input electrode C1
13 --- NC ---
14 Output N Output electrode N (pp-modulator)
15 --- NC ---
3.5.3 IR interface
The MicroSmart MC is equipped with an IrDA interface. This interface has the following
properties:
* Transmission rate: 9600 Baud
* Data bits: 8
* Stop bits: 1
* Parity: no
* no hardware handshake
* half duplex
* Range max. 3 meters (direct visual connection to receiver)
