MARS COMMERCE GSW2 PLUS - Figure 2: GSW2 PLUS: Connection Table

GSW2 PLUS
USER MANUAL
Page 10
PS
Power supply
BATT+
Back-up Battery connection
PS
BATT-
IN1
Alarm input 1 / Call button 1
G
GSM Intercom – Call point
connections
IN2
Alarm input 2 / Call button 1
B
1C
Relay output 1 – Common
W
1NC
Relay output 1 – Normal Close
Y
1NO
Relay output 1 – Normal Open
CB1
2C
Relay output 2 – Common
AUX
2NC
Relay output 2 – Normal Close
GND
2NO
Relay output 2 – Normal Open
WIEGAND
Wiegand input connector
AUX
+12V AUX max. 100 mA in total!
ANT
GSM Antenna
GND
Ground
USB
USB conn. for programming with PC
OUT 3
Wiegand output D0
OUT 4
Wiegand output D1
GND
Ground
A
RS485 A
B
RS485 B
TMP
Temperature probe connector
Figure 2: GSW2 PLUS: Connection table.
IMPORTANT
DO NOT USE Power out (12V AUX) for electric lock driving! Use
separate power source for door electric lock!
